Steyr 4100 Profi

Built: 2003–2007 · Series: Profi-Baureihe

More machines from model year 2003

Source: https://www.technikboerse.com/gebraucht/traktor-357/steyr-11

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Steyr 4100 Profi is a model in the Profi series. Production: 2003–2007. The engine delivers 101 hp (74.3 kW), has 4 cylinders, with a displacement of 4,485 cm³. Torque is 435 Nm. Rated speed is 2,200 rpm. The machine is 4,265 mm long, 1,873 mm wide and 2,876 mm high. The unladen weight is 5,080 kg. The wheelbase measures 2,412 mm. Ground clearance is 350 mm. Top speed is 30 km/h. The tank holds 180 litres. Transmission: 16V/16R, 24V/24R and 17V/16R. The engine is water-cooled. Tyres: front 480/65 R 28 AS, rear 600/65 R 38 AS. The fuel is Diesel/RME. The bore measures 104 mm. The stroke is 132 mm. Maximum torque is reached at 1,400 rpm. Construction: unit construction (no separate frame). The linkage is category II. The PTO runs at 540/540E/1000 rpm. The Profi-Baureihe series covers 5 models. Rated output within it ranges from 101 to 136 hp; the 4100 Profi sits at the bottom of that range with 101 hp. Its immediate neighbours are the 4115 Profi above it with 116 hp. Unladen weight within it ranges from 4,940 to 5,350 kg; here the 4100 Profi sits in the lower part of that range with 5,080 kg. 137 Steyr models across 20 series are on record.

Steyr Profi range – four- and six-cylinder tractors from St. Valentin: 4100/4115 Profi and 6115 to 6135 Profi, 74 to 100 kW, diesel or RME

The Steyr Profi range from St. Valentin adds a bigger six-cylinder variant to the Expert range alongside the four-cylinder chassis. The designations 4100 and 4115 Profi carry the 4.5-litre four-cylinder, 6115 to 6135 Profi the bigger six-cylinder; the last digits each give the power class in hp. The engines run on either diesel or the biodiesel RME.

Read on 3 more paragraphs

The register lists here 5 versions with 74.3 to 100.1 kW or 101 to 136 hp from four- to six-cylinders of 4,485 to 6,728 cc, unladen weights from 4,940 to 5,350 kg, lengths from 4,265 to 4,532 mm, widths from 1,873 to 1,913 mm and heights from 2,876 to 2,920 mm, torque from 435 to 612 Nm at a rated speed of 2,200 rpm.

The Profi range covers the mid to upper class of all-round tractors in the Steyr programme, for mixed farms with fodder growing, arable farming and haulage work in Austria, southern Germany and the alpine countries. The parallel four- and six-cylinder layout allows a choice between a more compact build and higher torque.

On the Profi range, what counts is operating hours, the condition of clutch and gearbox, the tightness of the hydraulics, the condition of the four-wheel-drive clutch, and on RME operation the fuel lines and injection system; parts run through the CNH and Steyr network, though parts for the six-cylinder can be harder to source than for the four-cylinder.

Sources: SpecCodex register, model data: Steyr Profi-Baureihe, Steyr (CNH, Hersteller)

Technical data

Engine

Fuel	Diesel/RMEcorrect
Power	101 hp (74.3 kW)correct
Rated speed	2,200 rpmcorrect
Torque	435 Nmcorrect
Speed at max. torque	1,400 rpmcorrect
Cylinders	4correct
Displacement	4,485 cm³correct
Bore	104 mmcorrect
Stroke	132 mmcorrect
Cooling	water-cooledcorrect

Dimensions and weights

Length	4,265 mmcorrect
Width	1,873 mmcorrect
Height	2,876 mmcorrect
Wheelbase	2,412 mmcorrect
Ground clearance	350 mmcorrect
Unladen weight	5,080 kgcorrect

Drivetrain and chassis

Drive	four-wheel drivecorrect
Gearbox	16V/16R, 24V/24R and 17V/16Rcorrect
Front tyres	480/65 R 28 AScorrect
Rear tyres	600/65 R 38 AScorrect
Top speed	30 km/hcorrect

Working data

Fuel tank capacity	180 lcorrect

Origin and approval

Construction	unit construction (no separate frame)correct

Other data

Linkage category	Cat IIcorrect
PTO speed	540/540E/1000 rpmcorrect

Where this model stands

Power-to-weight ratio: 14.6 kW/t (74 kW / 5.1 t)

Power class: Large (100–180 hp)

Stronger than 67% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Steyr 4100 Profi have?

The Steyr 4100 Profi delivers 101 hp.

How much does the Steyr 4100 Profi weigh?

The unladen weight is 5,080 kg.

What engine does the Steyr 4100 Profi have?

4 cylinders, 4,485 cm³ displacement, Diesel/RME.

How fast does the Steyr 4100 Profi go?

Top speed is 30 km/h.

What are the dimensions of the Steyr 4100 Profi?

4,265 mm × 1,873 mm × 2,876 mm.

When was the Steyr 4100 Profi built?

Production years: 2003–2007.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
