Steyr 9080 M
Built: 2004–2007 · Series: 9000 M
More machines from model year 2004
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Steyr CNH 9000 M – the mid four-cylinder range with Steyr's own engine: 9080 M and 9090 M, 60 to 66 kW (82 to 89 hp), 4,397 cc, also approved for rapeseed diesel
The 9000 M range represents Steyr's mid four-cylinder class after joining the Case/CNH group, with the 9080 M and 9090 M as two closely spaced power steps; the last two digits roughly denote the horsepower. The engine comes from Steyr itself, which continues to build its own diesel units within the group, while the chassis and cab share technical solutions with Case IH.
Read on 3 more paragraphs
The register lists 2 variants at 60 to 66 kW (82 to 89 hp) from a four-cylinder diesel of 4,397 cc, kerb weights of 3,750 to 3,950 kg, lengths of 3,980 to 4,215 mm, a width of 2,170 mm, a height of 2,690 mm and a rated 2,300 rpm; one model is also approved for rapeseed diesel.
In this mid power class the 9000 M range served classic mixed arable and grassland farms in Austria and southern Germany, competing directly with comparable models from Fendt Farmer, Deutz-Fahr Agrotron and John Deere's 6000 series.
Buying one of these four-cylinder tractors, the condition of the injection pump and turbocharger matters, along with hydraulic tightness, wear on the clutch and gearbox, and rust on the frame and wings; parts for Steyr's own engine run through the CNH dealer network; the axles are also worth checking for bearing play and seal condition, and on the rapeseed-diesel model the fuel lines and their fittings as well.
Sources: SpecCodex register, model data: Steyr CNH 9000 M, Steyr (manufacturer)
Technical data
Engine
| Engine make | Steyrcorrect |
|---|---|
| Fuel | dieselcorrect |
| Power | 82 hp (60 kW)correct |
| Rated speed | 2,300 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 4,397 cm³correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,980 mmcorrect |
|---|---|
| Width | 2,170 mmcorrect |
| Height | 2,690 mmcorrect |
| Wheelbase | 2,424 mmcorrect |
| Unladen weight | 3,750 kgcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 16V / 16Rcorrect |
| Front tyres | 9.00-16 (A = 14.9R24)correct |
| Rear tyres | 18.4R34correct |
| Top speed | 30 km/hcorrect |
Origin and approval
| Plant | St. Valentin, Austriacorrect |
|---|
Other data
| PTO speed | 1,000 rpmcorrect |
|---|
Where this model stands
Power-to-weight ratio: 16 kW/t (60 kW / 3.8 t)
Power class: Universal (40–100 hp)
Stronger than 56% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Steyr 9080 M have?
The Steyr 9080 M delivers 82 hp.
How much does the Steyr 9080 M weigh?
The unladen weight is 3,750 kg.
What engine does the Steyr 9080 M have?
4 cylinders, 4,397 cm³ displacement, Diesel.
How fast does the Steyr 9080 M go?
Top speed is 30 km/h.
What are the dimensions of the Steyr 9080 M?
3,980 mm × 2,170 mm × 2,690 mm.
When was the Steyr 9080 M built?
Production years: 2004–2007.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
