Scania P270 DB4X2MNB – specifications
Built: 2005 · Series: P270
The P270 DB4X2MNB from Scania is part of the P270 series. Production: 2005. The engine has 5 cylinders, with a displacement of 8,867 cm³. The vehicle is 9,480 mm long and 2,500 mm wide. The unladen weight is 8,160 kg. The wheelbase measures 5,300 mm. The gross vehicle weight is 19,500 kg. The vehicle runs on 4 wheels. The P270 series covers 7 models. Unladen weight within it ranges from 6,630 to 11,160 kg; the P270 DB4X2MNB sits in the lower part of that range with 8,160 kg. Its immediate neighbours are the P270 DA4X2MNA below it with 6,630 kg and the P270 4X2 above it with 9,025 kg. Gross vehicle weight within it ranges from 18,200 to 26,500 kg; here the P270 DB4X2MNB sits in the lower part of that range with 19,500 kg. 11893 Scania models across 91 series are on record.
Data for the version built 2005 · Data origin: Official register · sources
More machines from model year 2005
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Scania P270 – distribution and construction chassis with P-cab: 270 hp five- and six-cylinder of 8.9 litres, 4X2 and 6X2 axle formulas, gross weights from 18,200 to 26,500 kg
The Scania P270 carries the P-cab, the short and low forward-control cab of Scania's range programmes for distribution work, construction sites and municipal service. The number 270 gives the engine output in horsepower; the axle formulas 4X2 and 6X2 in the model designations state the number of axles and driven axles of the respective chassis, and the suffix SCAPP denotes special chassis equipment.
Read on 4 more paragraphs
The register lists 7 versions with 198 kW from five- and six-cylinder engines of 8,867 to 8,870 cc. Kerb weights range from 6,630 to 11,160 kg, gross vehicle weights from 18,200 to 26,500 kg. Lengths run from 5,790 to 9,725 mm, widths from 2,500 to 2,600 mm.
With the P-cab, the P270 covers the segment occupied by the short-cab Mercedes-Benz Actros and the P-cab Volvo FE/FM; as a chassis for tipper, concrete-mixer and municipal bodies it is widespread in construction traffic.
On a used example, checks should cover corrosion on the frame outriggers and spring brackets, the condition of the clutch and gearbox under frequent loaded pull-away, sealing of the charge-air cooler and turbocharger, and on 6X2 chassis the condition of the tag axle; spare parts are widely available through Scania's service network.
With gross vehicle weights from 18,200 to 26,500 kg, these chassis belong to EU class N3 (over 12 t); operating them requires a category CE driving licence, a tachograph and compliance with driving and rest times, plus, on toll roads, a distance-based toll. The P-cab without a sleeping berth suits the chassis to day work, while air suspension on the rear axle combines ride comfort with the reserve needed for high axle loads on construction-site tracks.
Sources: SpecCodex register, model data: Scania P270
Technical data
Engine
| Cylinders | 5correct |
|---|---|
| Displacement | 8,867 cm³correct |
Dimensions and weights
| Length | 9,480 mmcorrect |
|---|---|
| Width | 2,500 mmcorrect |
| Wheelbase | 5,300 mmcorrect |
| Unladen weight | 8,160 kgcorrect |
| Gross vehicle weight | 19,500 kgcorrect |
Drivetrain and chassis
| Wheels | 4correct |
|---|
Frequently asked questions
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
