SAME GOLDEN 85 COMPATTO
Built: 1998–2003 · Series: GOLDEN-Baureihe
More machines from model year 1998
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
SAME Golden series: compact Compatto tractors from the SDF group in Treviglio, four types from Golden 60 to 85 Compatto, 44.1 to 62.5 kW (60 to 85 hp), four-wheel-drive DT variants, 2,200 to 2,510 kg kerb weight
The Golden series denotes, at SAME of Treviglio under the SDF group, a range of compact field tractors carrying the Compatto suffix. The models Golden 60, 65 (DT), 75 and 85 Compatto rank the types by power class in hp; the DT abbreviation stands, in Italian tractor nomenclature, for Doppia Trazione, meaning four-wheel drive. The Compatto suffix underlined the shortened wheelbase and tight turning circle that set these models apart from SAME's standard-length tractors.
Read on 3 more paragraphs
The register lists 4 versions with 44.1 to 62.5 kW, or 60 to 85 hp, from three- to four-cylinder engines of 3,000 to 4,000cc, torque from 180 to 279 Nm at 2,350 rpm, kerb weights from 2,200 to 2,510 kg, lengths from 3,431 to 3,671 mm and a consistent width of 1,290 mm and height of 2,110 mm.
The Golden series' compact build targeted farms with limited space, such as orchards and vineyards and hilly terrain, where a low centre of gravity and narrow dimensions were needed alongside sufficient engine power. The compact build also eased manoeuvring in tight farmyards and machine sheds.
When buying used, check clutch and gearbox condition, engine and hydraulic oil-tightness, the function of the four-wheel drive on DT versions, and corrosion on the cab and chassis; spare parts supply runs through the SDF dealer network for the SAME brand.
Sources: SpecCodex register, model data: SAME Golden-Baureihe, SAME (SDF Group, Hersteller)
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 85 hp (62.5 kW)correct |
| Rated speed | 2,350 rpmcorrect |
| Torque | 279 Nmcorrect |
| Speed at max. torque | 1,520 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 4,000 cm³correct |
| Bore | 105 mmcorrect |
| Stroke | 115.5 mmcorrect |
| Compression ratio | 16correct |
| Cooling | air-cooledcorrect |
Dimensions and weights
| Length | 3,561 mmcorrect |
|---|---|
| Width | 1,290 mmcorrect |
| Height | 2,110 mmcorrect |
| Wheelbase | 2,056 mmcorrect |
| Ground clearance | 230 mmcorrect |
| Unladen weight | 2,510 kgcorrect |
Drivetrain and chassis
| Drive | four-wheel drivecorrect |
|---|---|
| Gearbox | 16 V/8 R, 24 V/12 R, 30 V/15 R and 45 V/45 Rcorrect |
| Front tyres | 260/70 R 16 AScorrect |
| Rear tyres | 380/70 R 24 AScorrect |
| Top speed | 40 km/hcorrect |
Working data
| Fuel tank capacity | 55 lcorrect |
|---|
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|
Other data
| Linkage category | Cat IIcorrect |
|---|
Where this model stands
Power-to-weight ratio: 24.9 kW/t (62 kW / 2.5 t)
Power class: Universal (40–100 hp)
Stronger than 58% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the SAME GOLDEN 85 COMPATTO have?
The SAME GOLDEN 85 COMPATTO delivers 85 hp.
How much does the SAME GOLDEN 85 COMPATTO weigh?
The unladen weight is 2,510 kg.
What engine does the SAME GOLDEN 85 COMPATTO have?
4 cylinders, 4,000 cm³ displacement, Diesel.
How fast does the SAME GOLDEN 85 COMPATTO go?
Top speed is 40 km/h.
What are the dimensions of the SAME GOLDEN 85 COMPATTO?
3,561 mm × 1,290 mm × 2,110 mm.
When was the SAME GOLDEN 85 COMPATTO built?
Production years: 1998–2003.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
