SAME GOLDEN 65 COMPATTO (DT)

Built: 1998–2003 · Series: GOLDEN-Baureihe

More machines from model year 1998

Source: https://www.same-tractors.com/de-de/traktoren/explorer-natur

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The GOLDEN series from SAME includes the GOLDEN 65 COMPATTO (DT). Production: 1998–2003. The engine delivers 67 hp (49.3 kW), has 3 cylinders, with a displacement of 3,000 cm³. Torque is 227 Nm. Rated speed is 2,350 rpm. The machine is 3,431 mm long, 1,290 mm wide and 2,110 mm high. The unladen weight is 2,200 kg. The wheelbase measures 1,926 mm. Ground clearance is 230 mm. Top speed is 40 km/h. Transmission: 16 V/8 R, 30 V/15 R and 45 V/45 R. The engine is air-cooled. Tyres: front 240/70 R 16 AS, rear 380/70 R 20 AS. The fuel is diesel. The bore measures 105 mm. The stroke is 115.5 mm. The compression ratio is 16:1. Maximum torque is reached at 1,795 rpm. Construction: unit construction (no separate frame). The GOLDEN-Baureihe series covers 4 models. Rated output within it ranges from 60 to 85 hp; the GOLDEN 65 COMPATTO (DT) sits in the lower part of that range with 67 hp. Its immediate neighbours are the GOLDEN 60 COMPATTO below it with 60 hp and the GOLDEN 75 COMPATTO above it with 75 hp. Unladen weight within it ranges from 2,200 to 2,510 kg; here the GOLDEN 65 COMPATTO (DT) sits at the bottom of that range with 2,200 kg. 265 SAME models across 29 series are on record.

SAME Golden series: compact Compatto tractors from the SDF group in Treviglio, four types from Golden 60 to 85 Compatto, 44.1 to 62.5 kW (60 to 85 hp), four-wheel-drive DT variants, 2,200 to 2,510 kg kerb weight

The Golden series denotes, at SAME of Treviglio under the SDF group, a range of compact field tractors carrying the Compatto suffix. The models Golden 60, 65 (DT), 75 and 85 Compatto rank the types by power class in hp; the DT abbreviation stands, in Italian tractor nomenclature, for Doppia Trazione, meaning four-wheel drive. The Compatto suffix underlined the shortened wheelbase and tight turning circle that set these models apart from SAME's standard-length tractors.

Read on 3 more paragraphs

The register lists 4 versions with 44.1 to 62.5 kW, or 60 to 85 hp, from three- to four-cylinder engines of 3,000 to 4,000cc, torque from 180 to 279 Nm at 2,350 rpm, kerb weights from 2,200 to 2,510 kg, lengths from 3,431 to 3,671 mm and a consistent width of 1,290 mm and height of 2,110 mm.

The Golden series' compact build targeted farms with limited space, such as orchards and vineyards and hilly terrain, where a low centre of gravity and narrow dimensions were needed alongside sufficient engine power. The compact build also eased manoeuvring in tight farmyards and machine sheds.

When buying used, check clutch and gearbox condition, engine and hydraulic oil-tightness, the function of the four-wheel drive on DT versions, and corrosion on the cab and chassis; spare parts supply runs through the SDF dealer network for the SAME brand.

Sources: SpecCodex register, model data: SAME Golden-Baureihe, SAME (SDF Group, Hersteller)

Technical data

Engine

Fuel	dieselcorrect
Power	67 hp (49.3 kW)correct
Rated speed	2,350 rpmcorrect
Torque	227 Nmcorrect
Speed at max. torque	1,795 rpmcorrect
Cylinders	3correct
Displacement	3,000 cm³correct
Bore	105 mmcorrect
Stroke	115.5 mmcorrect
Compression ratio	16correct
Cooling	air-cooledcorrect

Dimensions and weights

Length	3,431 mmcorrect
Width	1,290 mmcorrect
Height	2,110 mmcorrect
Wheelbase	1,926 mmcorrect
Ground clearance	230 mmcorrect
Unladen weight	2,200 kgcorrect

Drivetrain and chassis

Drive	four-wheel drivecorrect
Gearbox	16 V/8 R, 30 V/15 R and 45 V/45 Rcorrect
Front tyres	240/70 R 16 AScorrect
Rear tyres	380/70 R 20 AScorrect
Top speed	40 km/hcorrect

Origin and approval

Construction	unit construction (no separate frame)correct

Where this model stands

Power-to-weight ratio: 22.4 kW/t (49 kW / 2.2 t)

Power class: Universal (40–100 hp)

Stronger than 46% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the SAME GOLDEN 65 COMPATTO (DT) have?

The SAME GOLDEN 65 COMPATTO (DT) delivers 67 hp.

How much does the SAME GOLDEN 65 COMPATTO (DT) weigh?

The unladen weight is 2,200 kg.

What engine does the SAME GOLDEN 65 COMPATTO (DT) have?

3 cylinders, 3,000 cm³ displacement, Diesel.

How fast does the SAME GOLDEN 65 COMPATTO (DT) go?

Top speed is 40 km/h.

What are the dimensions of the SAME GOLDEN 65 COMPATTO (DT)?

3,431 mm × 1,290 mm × 2,110 mm.

When was the SAME GOLDEN 65 COMPATTO (DT) built?

Production years: 1998–2003.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.
