SAME Lamborghini Hürlimann LASER 110 (DT) – specifications
Built: 1983–1996 · Series: LASER-Baureihe
The SAME Lamborghini Hürlimann LASER 110 (DT) is a model in the LASER series. Production: 1983–1996. The engine delivers 109 hp (80.2 kW), has 6 cylinders, with a displacement of 5,655 cm³. Torque is 365 Nm. Rated speed is 2,200 rpm. The machine is 4,035 mm long, 2,120 mm wide and 2,695 mm high. The unladen weight is 4,340 kg. The wheelbase measures 2,767 mm. Ground clearance is 600 mm. Top speed is 30 km/h. Transmission: 12 V/ 3 R, 24 V/12 R and 20 V/12 R. The engine is air-cooled. Tyres: front 10.00-16 ASF (DT: 16.9-24 AS), rear 18.4-34 AS. The fuel is diesel. The bore measures 100 mm. The stroke is 120 mm. The compression ratio is 17:1. Maximum torque is reached at 1,400 rpm. Construction: unit construction (no separate frame). Injection pressure is 215 bar. The LASER-Baureihe series covers 3 models. Rated output within it ranges from 109 to 145 hp; the LASER 110 (DT) sits at the bottom of that range with 109 hp. Its immediate neighbours are the LASER 130 DT above it with 125 hp. Unladen weight within it ranges from 4,340 to 5,590 kg; here the LASER 110 (DT) sits at the bottom of that range with 4,340 kg. 54 SAME Lamborghini Hürlimann models across 9 series are on record.
Data for the version built 1983–1996 · Data origin: Reference work (Wikipedia/Wikibooks) · sources
More machines from model year 1983
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
SAME Lamborghini Hürlimann Laser range: collective page of powerful six-cylinder tractors, Laser 110 to 150, from the shared SLH platform, 80 to 107 kW, 1980s/90s
The Laser range was developed on the shared technical platform of the three SDF brands SAME, Lamborghini and Hürlimann (SLH) and was sold in parallel under all three names during the 1980s and 1990s. The model designations 110, 130 and 150 rank the range by power class, and the DT suffix stands for Doppia Trazione, four-wheel drive; all three versions in the register are four-wheel-drive models.
Read on 3 more paragraphs
The register lists 3 versions with 80.2 to 106.6 kW from six-cylinder diesel engines of 5,655 to 6,235 cm³, unladen weights of 4,340 to 5,590 kg, lengths of 4,035 to 4,510 mm, widths of 2,120 to 2,170 mm and heights of 2,695 to 2,810 mm; torque ranges from 365 to 488 Nm at 2,180 to 2,260 rpm.
In this power class the Laser models handled heavy field work such as deep ploughing and driving large implements, competing with the standard tractors of Fiat, Deutz-Fahr and Ford; the shared platform of the three brands cut development costs and gave largely identical engineering under different badges.
When buying used, condition of the six-cylinder diesel including cooling and injection, the transmission and four-wheel drive under load, and the hydraulics and lift all matter; since the engineering is identical across the three brands, spare parts can often be sourced through any of the three SDF dealer networks.
Sources: SpecCodex register, model data: SAME Lamborghini Hürlimann Laser
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 109 hp (80.2 kW)correct |
| Rated speed | 2,200 rpmcorrect |
| Torque | 365 Nmcorrect |
| Speed at max. torque | 1,400 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 5,655 cm³correct |
| Bore | 100 mmcorrect |
| Stroke | 120 mmcorrect |
| Compression ratio | 17correct |
| Injection pressure | 215 barcorrect |
| Cooling | air-cooledcorrect |
Dimensions and weights
| Length | 4,035 mmcorrect |
|---|---|
| Width | 2,120 mmcorrect |
| Height | 2,695 mmcorrect |
| Wheelbase | 2,767 mmcorrect |
| Ground clearance | 600 mmcorrect |
| Unladen weight | 4,340 kgcorrect |
Drivetrain and chassis
| Drive | rear- or four-wheel drivecorrect |
|---|---|
| Gearbox | 12 V/ 3 R, 24 V/12 R and 20 V/12 Rcorrect |
| Front tyres | 10.00-16 ASF (DT: 16.9-24 AS)correct |
| Rear tyres | 18.4-34 AScorrect |
| Top speed | 30 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|
Frequently asked questions
Where this model stands
Power-to-weight ratio: 18.5 kW/t (80 kW / 4.3 t)
Power class: Large (100–180 hp)
Stronger than 70% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
