Renault N 31
Built: 1/1957–12/1962 · Series: N-Baureihe
More machines from model year 1957
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Renault N series tractors from Le Mans in the 1950s: N 31 to N 73, two- to four-cylinder engines of 1,400 to 2,715 cc, 12 to 29 kW, MWM diesels and one petrol engine
Renault began building farm machinery as early as the 1920s and, from the 1950s, built the N series at its Le Mans plant, the numbered successor to the brand's first post-war tractors. The models N 31, N 70, N 71, N 72 and N 73 cover the small to medium power class of those years, with two- to four-cylinder engines; some of the units came from the German engine maker MWM, including the AKD 112 Z.
Read on 3 more paragraphs
The register lists here 5 versions with 11.8 to 29.4 kW from two- to four-cylinders of 1,400 to 2,715 cc, unladen weights from 1,045 to 1,695 kg, lengths from 2,720 to 3,130 mm and widths from 1,500 to 1,570 mm at a rated speed of 2,000 rpm. Four of the models run on diesel, one on petrol.
In the 1950s Renault was, alongside Someca, SFV and the big international brands, one of the French suppliers of farm equipment during the rebuilding of agriculture; the N series served small to medium-sized farms, before later ranges from the maker followed.
On these tractors, what counts today is above all the condition of the bodywork and mudguards, the condition of radiator and cylinder-head gasket on the older two-cylinders, the working order of the mechanical brakes and steering, and the originality of the data plate and paintwork; parts for these early models can mostly still be found only through collectors and specialist vintage-parts dealers.
Sources: SpecCodex register, model data: Renault N-Baureihe
Technical data
Engine
| Fuel | petrolcorrect |
|---|---|
| Power | 40 hp (29.4 kW)correct |
| Rated speed | 2,000 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 2,141 cm³correct |
| Bore | 88 mmcorrect |
| Stroke | 88 mmcorrect |
| Compression ratio | 7.5correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,130 mmcorrect |
|---|---|
| Width | 1,570 mmcorrect |
| Height | 1,540 mmcorrect |
| Wheelbase | 1,750 mmcorrect |
| Ground clearance | 400 mmcorrect |
| Unladen weight | 1,545 kgcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 6V/1R or 10V/2Rcorrect |
| Front tyres | 6.50-16 ASFcorrect |
| Rear tyres | 12-28 AScorrect |
| Top speed | 25 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|---|
| Units built | 732correct |
Where this model stands
Power-to-weight ratio: 19 kW/t (29 kW / 1.5 t)
Power class: Compact (< 40 hp)
Stronger than 25% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Renault N 31 have?
The Renault N 31 delivers 40 hp.
How much does the Renault N 31 weigh?
The unladen weight is 1,545 kg.
What engine does the Renault N 31 have?
4 cylinders, 2,141 cm³ displacement, Benzin.
How fast does the Renault N 31 go?
Top speed is 25 km/h.
What are the dimensions of the Renault N 31?
3,130 mm × 1,570 mm × 1,540 mm.
When was the Renault N 31 built?
Production years: 1/1957–12/1962.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
