Renault 410.35 6X6 H
Built: 2009 · Series: Kerax
More machines from model year 2009
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Renault Kerax – the construction truck from the 260.19 to the 520.42: type code from engine power in hp and gross weight in tonnes, 4×4 to 8×4
The Renault Kerax is the construction and heavy-duty truck introduced in 1997 by Renault Véhicules Industriels, replacing the Major/Maxter and built until 2013 as a tipper, concrete-mixer chassis and off-road tractor unit. The type designation gives the engine power in horsepower before the separator and the gross weight in tonnes after it, for instance the Kerax 420.34 with about 420 hp and a 34-tonne gross weight; the following codes such as 4X4, 6X4, 6X6 and 8X4 give the number of wheels and driven axles.
Read on 3 more paragraphs
The register lists here 23 versions with 188 to 368 kW output, displacements from 9,830 to 12,800 cm³, unladen weights from 7,370 to 30,800 kg, gross weights from 11,990 to 51,000 kg, lengths from 6,900 to 10,690 mm and widths from 2,500 to 2,550 mm.
Alongside the Mercedes-Benz Actros/Arocs and the MAN TGS, the Kerax was a standard vehicle in the construction and mining trades, especially in all-wheel-drive form for unpaved terrain; after Renault Trucks renamed its ranges, the successor has traded since 2013 as the C range.
On a used purchase, tippers and concrete-mixer chassis call for checking the condition of the subframe and body, the tightness of the transfer case on all-wheel-drive models, the braking system and suspension, and the engine's operating hours and service history; parts run through the Renault Trucks network.
Sources: SpecCodex register, model data: Renault Kerax, Renault Trucks (manufacturer)
Technical data
Engine
| Cylinders | 6correct |
|---|---|
| Displacement | 10,837 cm³correct |
Dimensions and weights
| Length | 9,700 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Wheelbase | 5,870 mmcorrect |
| Unladen weight | 18,060 kgcorrect |
| Gross vehicle weight | 28,000 kgcorrect |
Drivetrain and chassis
| Wheels | 6correct |
|---|
Frequently asked questions
How much does the Renault 410.35 6X6 H weigh?
The unladen weight is 18,060 kg.
What is the gross vehicle weight of the Renault 410.35 6X6 H?
28,000 kg.
What engine does the Renault 410.35 6X6 H have?
6 cylinders, 10,837 cm³ displacement.
What are the dimensions of the Renault 410.35 6X6 H?
9,700 mm × 2,550 mm.
When was the Renault 410.35 6X6 H built?
Production years: 2009.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 10 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
