New Holland TD 60D
Series: TD
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The New Holland TD 60D belongs to the entry‑level tractor series TD, manufactured in Turkey and India. It is a diesel tractor with three cylinders and a displacement of 2 931 cm³. The model follows the TD naming convention where the two‑digit number before the letter D indicates the power class.
It delivers a rated power of 59 hp (43.4 kW) at a nominal engine speed of 2 500 rpm and produces a maximum torque of 181 Nm. The transmission options include 12 forward and 12 reverse gears (as well as versions with 20 forward and 12 reverse gears), providing flexible speed control for field operations. The fuel tank holds 90 l, and the pump shaft speed of 540 rpm (or 1000 rpm) supports lifting implements in the Cat I/II category. Its compact dimensions—width 1 799 mm and height 2 555 mm—facilitate maneuvering in tight rows.
Within the TD range the TD 60D ranks 6th out of 7 models, with a power span from 43.4 to 84 kW. The next larger model is the TD 5040 at 65 kW, while its power is practically equal to the TD 5010. This placement shows that the TD 60D occupies the lower power segment of the series.
New Holland TD – the entry-level range from Turkey and India, from the TD 60D and TD 95 to the TD 5 series (TD 5.75 to TD 5.115), 43.4 to 84 kW, three- and four-cylinders
This page gathers the versions of the New Holland TD, the brand's entry-level range, built in Turkey and in India. The older types TD 60D, TD 90D, TD 95 and TD 95D give the power class in the two-digit number before the letter D for the diesel version; the newer TD 5.75 to TD 5.115 models follow the TD 5 logic, in which the digit after the point roughly gives the power class in hp.
Read on 3 more paragraphs
The register lists here 13 versions with 43.4 to 84 kW (59 to 99 hp) from three- and four-cylinders of 2,931 to 4,485 cm³ displacement, unladen weights of 3,420 to 3,900 kg, gross weights of 5,900 to 6,800 kg, lengths of 3,650 to 4,280 mm, widths of 1,799 to 2,550 mm, heights of 2,555 to 2,665 mm, torques of 181 to 325 Nm and rated speeds of 2,300 to 2,500 rpm.
The TD range positions New Holland as an affordable entry point below the European T4 and T5 ranges, mainly for markets outside Western Europe, where simple mechanics and a lower purchase cost matter.
On the used TD range, engine condition and the injection pump, clutch and gearbox, and rust on mudguards and cab count; parts run through the New Holland network, though availability on the older D types can vary by region.
Sources: SpecCodex register, model data: New Holland TD, New Holland Agriculture (manufacturer)
Technical data
Engine
| Power | 59 hp (43.4 kW)correct |
|---|---|
| Rated speed | 2,500 rpmcorrect |
| Torque | 181 Nmcorrect |
| Cylinders | 3correct |
| Displacement | 2,931 cm³correct |
Dimensions and weights
| Width | 1,799 mmcorrect |
|---|---|
| Height | 2,555 mmcorrect |
Drivetrain and chassis
| Gearbox | 12 V/12 R, 20 V/12 R and 12 V/4 Rcorrect |
|---|
Working data
| Fuel tank capacity | 90 lcorrect |
|---|
Other data
| Linkage category | Cat I/IIcorrect |
|---|---|
| PTO speed | 540/540E/1000 rpmcorrect |
Frequently asked questions
How much power does the New Holland TD 60D have?
The New Holland TD 60D delivers 59 hp.
What engine does the New Holland TD 60D have?
3 cylinders, 2,931 cm³ displacement.
What are the dimensions of the New Holland TD 60D?
1,799 mm × 2,555 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
