Start › Tractors › New Holland Geotech › TS series › TS 115 ES

New Holland Geotech TS 115 ES

Built: 1998–2003 · Series: TS-Baureihe

More machines from model year 1998

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The TS series from New Holland Geotech includes the TS 115 ES. Production: 1998–2003. The engine delivers 100 hp (73.6 kW), has 6 cylinders, with a displacement of 7,480 cm³. Torque is 420 Nm. Rated speed is 2,070 rpm. The machine is 4,397 mm long, 2,180 mm wide and 2,788 mm high. The unladen weight is 4,802 kg. The wheelbase measures 2,623 mm. Ground clearance is 418 mm. Top speed is 40 km/h. Transmission: 16 V/16 R and 24 V/24 R. The engine is water-cooled. Tyres: front 14.9 R 28 AS, rear 18.4 R 38 AS. The fuel is diesel. The bore measures 111.8 mm. The stroke is 127 mm. The compression ratio is 17.5:1. Maximum torque is reached at 1,134 rpm. Construction: unit construction (no separate frame). The TS-Baureihe series covers 4 models. Rated output within it ranges from 80 to 108 hp; the TS 115 ES sits in the upper part of that range with 100 hp. Its immediate neighbours are the TS 100 (A) below it with 90 hp and the TS 110 (A) above it with 108 hp. Unladen weight within it ranges from 3,929 to 4,802 kg; here the TS 115 ES sits at the top of that range with 4,802 kg. 32 New Holland Geotech models across 8 series are on record.

New Holland TS series: multi-purpose tractors from the Basildon plant of the 1990s, four types from TS 90 to TS 115 ES, 58.9 to 84.1 kW from four- and six-cylinder engines of 4,987 to 7,480cc

The TS series was introduced in the mid-1990s at New Holland's Basildon plant in Essex, the former Ford tractor factory, as successor to the Ford 40 series and forerunner of the later TM range. TS denotes the mid-to-upper multi-purpose class, available with either a four- or six-cylinder engine; the ES suffix marks a trim level with an electronically controlled powershift step. The model numbers 90 to 115 rank the tractors by power class.

Read on 3 more paragraphs

The register lists 4 versions with 58.9 to 84.1 kW from four- to six-cylinder engines of 4,987 to 7,480cc, torque from 325 to 426 Nm at 2,070 to 2,170 rpm, kerb weights from 3,929 to 4,802 kg, lengths from 3,810 to 4,397 mm, widths from 2,092 to 2,180 mm and heights from 2,726 to 2,788 mm.

The TS series positioned New Holland as a multi-purpose tractor for medium to larger arable farms across Western Europe, competing with the John Deere 6000 series, Case IH MX and Massey Ferguson 6100; Basildon production ensured a close technical kinship with the Case IH sister models.

When buying used, check operating hours, the condition of the powershift (especially on ES versions), engine and hydraulic oil-tightness, and cab suspension and air conditioning; wear parts are widely available through the CNH network, while the electronics of early ES versions are considered more failure-prone.

Sources: SpecCodex register, model data: New Holland TS-Baureihe, New Holland (CNH Industrial, Hersteller)

Technical data

Engine

Fuel	dieselcorrect
Power	100 hp (73.6 kW)correct
Rated speed	2,070 rpmcorrect
Torque	420 Nmcorrect
Speed at max. torque	1,134 rpmcorrect
Cylinders	6correct
Displacement	7,480 cm³correct
Bore	111.8 mmcorrect
Stroke	127 mmcorrect
Compression ratio	17.5correct
Cooling	water-cooledcorrect

Dimensions and weights

Length	4,397 mmcorrect
Width	2,180 mmcorrect
Height	2,788 mmcorrect
Wheelbase	2,623 mmcorrect
Ground clearance	418 mmcorrect
Unladen weight	4,802 kgcorrect

Drivetrain and chassis

Drive	four-wheel drivecorrect
Gearbox	16 V/16 R and 24 V/24 Rcorrect
Front tyres	14.9 R 28 AScorrect
Rear tyres	18.4 R 38 AScorrect
Top speed	40 km/hcorrect

Origin and approval

Construction	unit construction (no separate frame)correct

Where this model stands

Power-to-weight ratio: 15.3 kW/t (74 kW / 4.8 t)

Power class: Universal (40–100 hp)

Stronger than 66% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the New Holland Geotech TS 115 ES have?

The New Holland Geotech TS 115 ES delivers 100 hp.

How much does the New Holland Geotech TS 115 ES weigh?

The unladen weight is 4,802 kg.

What engine does the New Holland Geotech TS 115 ES have?

6 cylinders, 7,480 cm³ displacement, Diesel.

How fast does the New Holland Geotech TS 115 ES go?

Top speed is 40 km/h.

What are the dimensions of the New Holland Geotech TS 115 ES?

4,397 mm × 2,180 mm × 2,788 mm.

When was the New Holland Geotech TS 115 ES built?

Production years: 1998–2003.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
