Mccormick Deering FG D-2
Built: 1950 · Series: F-Reihe
More machines from model year 1950
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
McCormick-Deering F series – early standard tractors from International Harvester: DF 25, FG, FG D-2 and FS with two- to four-cylinder engines, 15 to 18 kW and diesel or petrol/kerosene power
The McCormick-Deering F series denotes early standard tractors under the McCormick-Deering brand, under which International Harvester sold its agricultural machinery in the first half of the 20th century. International Harvester was formed in 1902 from the merger of the McCormick Harvesting Machine Company with the Deering Harvester Company and other farm equipment makers; the double name remained in use as a tractor and harvester brand for decades. The four models DF 25 (A/T), FG, FG D-2 and FS differ in engine and fuel type: two of the four versions run on diesel, two on kerosene or petrol, reflecting the era's common practice of offering the same tractor type with different engine variants.
Read on 3 more paragraphs
The register lists 4 versions with 14.6 to 18.3 kW from two- to four-cylinder engines with 2,043 to 2,356 cm³ displacement. Unladen weights range from 1,700 to 1,970 kg, lengths from 3,040 to 3,180 mm, widths from 1,640 to 2,000 mm, and heights from 1,470 to 1,720 mm.
As standard tractors with a rigid frame and equal track width, the F series targeted farms that primarily needed draft power for tillage and belt work, unlike the narrower row-crop tractors of the same era. The choice between a diesel and a kerosene/petrol engine let farms match the tractor to locally available fuel.
On these historic tractors, the condition of the cylinder head and cooling system, the tightness of the fuel system depending on engine variant, wear on steering and clutch, and the condition of sheet metal and paintwork all matter. Spare parts for this vintage today come mainly from specialist vintage-tractor parts dealers and reproduction parts.
Sources: SpecCodex register, model data: McCormick-Deering F-Reihe
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 25 hp (18.3 kW)correct |
| Rated speed | 1,500 rpmcorrect |
| Cylinders | 2correct |
| Displacement | 2,356 cm³correct |
| Bore | 100 mmcorrect |
| Stroke | 150 mmcorrect |
| Injection pressure | 100 barcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,040 mmcorrect |
|---|---|
| Width | 2,000 mmcorrect |
| Height | 1,720 mmcorrect |
| Wheelbase | 1,840 mmcorrect |
| Ground clearance | 370 mmcorrect |
| Unladen weight | 1,970 kgcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 4 V/1 Rcorrect |
| Front tyres | 5.50-16correct |
| Rear tyres | 9.00-40correct |
| Top speed | 15 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|---|
| Units built | 58correct |
Where this model stands
Power-to-weight ratio: 9.3 kW/t (18 kW / 2 t)
Power class: Compact (< 40 hp)
Stronger than 12% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Mccormick Deering FG D-2 have?
The Mccormick Deering FG D-2 delivers 25 hp.
How much does the Mccormick Deering FG D-2 weigh?
The unladen weight is 1,970 kg.
What engine does the Mccormick Deering FG D-2 have?
2 cylinders, 2,356 cm³ displacement, Diesel.
How fast does the Mccormick Deering FG D-2 go?
Top speed is 15 km/h.
What are the dimensions of the Mccormick Deering FG D-2?
3,040 mm × 2,000 mm × 1,720 mm.
When was the Mccormick Deering FG D-2 built?
Production years: 1950.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 23 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
