Massey Ferguson MF 3125 (A)
Built: 1990–1995 · Series: 3100er-Serie
More machines from model year 1990
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Massey Ferguson 3100 series – the six-cylinder MF 3115 A to MF 3125 A tractors built at the French Beauvais plant with 84.6 to 92.7 kW, around 6 litres of displacement and 413 Nm of torque
The 3100 series was launched in the 1990s at the Massey Ferguson plant in Beauvais, northern France, and comprises the MF 3115 A, MF 3120 A and MF 3125 A models. The type number rises with engine output, while the A suffix marks the series as an updated version with a revised cab and hydraulics; all three models share the same six-cylinder engine at different output stages.
Read on 3 more paragraphs
The register lists 3 versions with 84.6 to 92.7 kW from six-cylinders of 5,985 to 5,987 cc displacement at a rated speed of 2,200 rpm. Maximum torque is 413 Nm. Operating weight ranges from 4,530 to 4,805 kg, length from 4,323 to 4,527 mm, width from 1,899 to 1,943 mm and height from 2,774 to 2,869 mm. All three models run on diesel.
With the 3100 series, Massey Ferguson positioned itself in the upper mid-range segment for mixed farming, between the more compact 3000 series and the larger 6100 series. The shared six-cylinder engine at three output stages allowed fine gradation without a separate engine development; the Beauvais plant built further ranges of the group alongside it, keeping development paths between the model stages short.
On a used purchase, points to check include the condition of the hydraulic pump and PTO, the tightness of the radiator and charge-air ducting, wear on the clutch and gearbox, and rust on the cab floor and mudguards. Spare parts remain well available through the AGCO network for Massey Ferguson.
Sources: SpecCodex register, model data: Massey Ferguson 3100er-Serie, Massey Ferguson (AGCO, Hersteller)
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 126 hp (92.7 kW)correct |
| Rated speed | 2,200 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 5,985 cm³correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 4,527 mmcorrect |
|---|---|
| Width | 1,943 mmcorrect |
| Height | 2,869 mmcorrect |
| Wheelbase | 2,696 mmcorrect |
| Ground clearance | 428 mmcorrect |
| Unladen weight | 4,805 kgcorrect |
Drivetrain and chassis
| Drive | rear- or four-wheel drivecorrect |
|---|---|
| Gearbox | 16V/16R or 32V/32Rcorrect |
| Front tyres | 11.00-16 ASF (A: 14.9 R 28 AS)correct |
| Rear tyres | 20.8 R 38 AScorrect |
| Top speed | 30 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|
Where this model stands
Power-to-weight ratio: 19.3 kW/t (93 kW / 4.8 t)
Power class: Large (100–180 hp)
Stronger than 76% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Massey Ferguson MF 3125 (A) have?
The Massey Ferguson MF 3125 (A) delivers 126 hp.
How much does the Massey Ferguson MF 3125 (A) weigh?
The unladen weight is 4,805 kg.
What engine does the Massey Ferguson MF 3125 (A) have?
6 cylinders, 5,985 cm³ displacement, Diesel.
How fast does the Massey Ferguson MF 3125 (A) go?
Top speed is 30 km/h.
What are the dimensions of the Massey Ferguson MF 3125 (A)?
4,527 mm × 1,943 mm × 2,869 mm.
When was the Massey Ferguson MF 3125 (A) built?
Production years: 1990–1995.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
