Leroy Somer FLSES160M – specifications
Series: FLSES
The Leroy Somer FLSES160M is a three-phase induction motor. The rated output is 11 kW. The motor is four-pole, which at 50 Hz gives a synchronous speed of 1,500 rpm. The rated voltage is 400 V. The housing is frame size 160 M in foot-mounted form. The protection class is IP55. The efficiency is 90.4 per cent at full load, 90.2 per cent at 75 per cent load and 88.6 per cent at half load. Mounting arrangements to IEC 60034-7: B3, B5 and B35. The motor is built in China. The figures come from the Australian MEPS register under the GEMS Determination 2012; measured to AS/NZS 1359.102.3:2000. Rated output across the Leroy Somer range ranges from 0.75 to 160 kW; the FLSES160M sits at the bottom of that range with 11 kW. Its immediate neighbours are the LSES132MTI below it with 7.5 kW and the FLSES160L above it with 15 kW. 103 Leroy Somer models are on record.
Build year not documented · Data origin: Official register · sources
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Leroy Somer – FLSES series at a glance
The FLSES series from Leroy Somer comprises 12 models in the register, in the Electric motors group. Rated power ranges from 11 to 75 kW. Listed in the register: FLSES160L, FLSES160M, FLSES160MA, FLSES160MB.
Sources: SpecCodex-Register (eigene Daten)
Technical data
Engine
| Rated output | 11 kWcorrect |
|---|
Electrical data
| Rated voltage | 400 Vcorrect |
|---|---|
| Number of poles | 4correct |
| Protection class | IP55correct |
| Frame size | 160 M (foot)correct |
| Mounting (IEC 60034-7) | B3, B5, B35correct |
| Efficiency at full load | 90.37 %correct |
| Efficiency at 75 % load | 90.15 %correct |
| Efficiency at half load | 88.58 %correct |
Origin and approval
| Country of manufacture | Chinacorrect |
|---|
Other data
| Standard applied | Greenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2012correct |
|---|---|
| Test method | AS/NZS 1359.102.3:2000correct |
Frequently asked questions
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
