Landini LEGEND 130
Series: LEGEND
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Legend 130 is a tractor from Landini’s Legend series. It is offered with a nominal power of 125 hp (91.9 kW) and has been part of the Italian manufacturer’s lineup since its introduction. The model features a six‑cylinder engine with a displacement of 5,985 cm³ and is available with either a 36 V/36 R or 72 V/72 R gearbox.
A peak torque of 457 Nm at 2,200 rpm provides ample pulling force for demanding field tasks. The curb weight of 5,970 kg results in low ground pressure, while the compact dimensions (length 5,420 mm, width 2,340 mm, height 2,580 mm, wheelbase 2,650 mm) give good maneuverability. A top speed of 40 km/h and a fuel tank capacity of 180 L enable long operations without frequent refuelling. The tractor is approved for the Cat II/III lift‑capacity category and can operate with pump speeds of 540/1000 rpm.
Power: Rank 2 of 5 models in the series with value (91.9 kW). Power: next smaller model LEGEND 105 with 75.8 kW. Power: next larger model 165 DT with 117.7 kW. Power: range of the series 75.8 to 117.7 kW. Curb weight: Rank 1 of 5 models in the series with value (5,970 kg). Curb weight: next smaller model LEGEND 105 with 5,410 kg. Curb weight: practically equal to 165 DT, 130 DT. Curb weight: range of the series 5,410 to 5,970 kg.
Landini Legend – Italian large tractors from Fabbrico: six-cylinders from 76 to 118 kW, DT denoting permanent four-wheel drive
Landini builds the Legend series at the Fabbrico plant in the province of Reggio Emilia, the brand's traditional home, now part of the Argo Tractors group alongside McCormick and Valpadana. The DT suffix stands for Doppia Trazione, four-wheel drive, and appears on most Legend models such as the 105 DT, 130 DT and 165 DT. The number in the type designation follows the rated output, while TECHNO denotes a higher specification variant.
Read on 3 more paragraphs
The register lists here 9 versions with 75.8 to 117.7 kW (103 to 125 hp) from six-cylinders of 5,985 cm³, unladen weights of 5,410 to 5,970 kg, lengths of 4,780 to 5,420 mm, widths of 2,340 to 2,480 mm and heights of 2,580 to 2,890 mm.
The Legend series was Landini's offering in the upper power segment and competed with Fendt, John Deere and its sister brand McCormick; the large-displacement six-cylinder engines were built for drawbar pull in heavy tillage and work with large implements.
When buying Legend models used, what counts is the condition of the four-wheel drive and transfer gearbox, the tightness of the hydraulics, rust on wings and cab frame, and the service history of the six-cylinder engine; spare parts run through Landini's Argo Tractors dealer network. The condition of the PTO and trailer brake valves also belongs on the checklist, along with the seals of the cooling system.
Sources: SpecCodex register, model data: Landini Legend, Landini (manufacturer)
Technical data
Engine
| Power | 125 hp (91.9 kW)correct |
|---|---|
| Rated speed | 2,200 rpmcorrect |
| Torque | 457 Nmcorrect |
| Cylinders | 6correct |
| Displacement | 5,985 cm³correct |
Dimensions and weights
| Length | 5,420 mmcorrect |
|---|---|
| Width | 2,340 mmcorrect |
| Height | 2,580 mmcorrect |
| Wheelbase | 2,650 mmcorrect |
| Unladen weight | 5,970 kgcorrect |
Drivetrain and chassis
| Gearbox | 36 V/36 R or 72 V/72 Rcorrect |
|---|---|
| Top speed | 40 km/hcorrect |
Working data
| Fuel tank capacity | 180 lcorrect |
|---|
Other data
| Linkage category | Cat II/IIIcorrect |
|---|---|
| PTO speed | 540/1000 rpmcorrect |
Where this model stands
Power-to-weight ratio: 15.4 kW/t (92 kW / 6 t)
Power class: Large (100–180 hp)
Stronger than 76% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Landini LEGEND 130 have?
The Landini LEGEND 130 delivers 125 hp.
How much does the Landini LEGEND 130 weigh?
The unladen weight is 5,970 kg.
What engine does the Landini LEGEND 130 have?
6 cylinders, 5,985 cm³ displacement.
How fast does the Landini LEGEND 130 go?
Top speed is 40 km/h.
What are the dimensions of the Landini LEGEND 130?
5,420 mm × 2,340 mm × 2,580 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 16 individual figures for this model. They come from 2 recorded sources; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
