Landini 165 DT
Built: 1997–2001 · Series: LEGEND
More machines from model year 1997
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Landini Legend – Italian large tractors from Fabbrico: six-cylinders from 76 to 118 kW, DT denoting permanent four-wheel drive
Landini builds the Legend series at the Fabbrico plant in the province of Reggio Emilia, the brand's traditional home, now part of the Argo Tractors group alongside McCormick and Valpadana. The DT suffix stands for Doppia Trazione, four-wheel drive, and appears on most Legend models such as the 105 DT, 130 DT and 165 DT. The number in the type designation follows the rated output, while TECHNO denotes a higher specification variant.
Read on 3 more paragraphs
The register lists here 9 versions with 75.8 to 117.7 kW (103 to 125 hp) from six-cylinders of 5,985 cm³, unladen weights of 5,410 to 5,970 kg, lengths of 4,780 to 5,420 mm, widths of 2,340 to 2,480 mm and heights of 2,580 to 2,890 mm.
The Legend series was Landini's offering in the upper power segment and competed with Fendt, John Deere and its sister brand McCormick; the large-displacement six-cylinder engines were built for drawbar pull in heavy tillage and work with large implements.
When buying Legend models used, what counts is the condition of the four-wheel drive and transfer gearbox, the tightness of the hydraulics, rust on wings and cab frame, and the service history of the six-cylinder engine; spare parts run through Landini's Argo Tractors dealer network. The condition of the PTO and trailer brake valves also belongs on the checklist, along with the seals of the cooling system.
Sources: SpecCodex register, model data: Landini Legend, Landini (manufacturer)
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 160 hp (117.7 kW)correct |
| Rated speed | 2,200 rpmcorrect |
| Torque | 577 Nmcorrect |
| Speed at max. torque | 1,400 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 5,985 cm³correct |
| Bore | 100 mmcorrect |
| Stroke | 127 mmcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 4,780 mmcorrect |
|---|---|
| Width | 2,480 mmcorrect |
| Height | 2,890 mmcorrect |
| Wheelbase | 2,800 mmcorrect |
| Ground clearance | 520 mmcorrect |
| Unladen weight | 5,880 kgcorrect |
Drivetrain and chassis
| Drive | four-wheel drivecorrect |
|---|---|
| Gearbox | 36 V/36 R or 72 V/72 Rcorrect |
| Front tyres | 540/65 R 28 AScorrect |
| Rear tyres | 650/65 R 38 AScorrect |
| Top speed | 40 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|
Where this model stands
Power-to-weight ratio: 20 kW/t (118 kW / 5.9 t)
Power class: Large (100–180 hp)
Stronger than 85% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Landini 165 DT have?
The Landini 165 DT delivers 160 hp.
How much does the Landini 165 DT weigh?
The unladen weight is 5,880 kg.
What engine does the Landini 165 DT have?
6 cylinders, 5,985 cm³ displacement, Diesel.
How fast does the Landini 165 DT go?
Top speed is 40 km/h.
What are the dimensions of the Landini 165 DT?
4,780 mm × 2,480 mm × 2,890 mm.
When was the Landini 165 DT built?
Production years: 1997–2001.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
