Landini R-7500 (DT)
Built: 1978–1987 · Series: 550 er-Baureihe
More machines from model year 1978
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Landini R-7500 (DT), 550 series – water-cooled four-cylinder diesel producing 70 hp at 2,200 rpm from 3,865 cc, with four-wheel drive (doppia trazione), built 1978 to 1987
Landini is one of Italy's oldest tractor manufacturers, founded by Giovanni Landini in the town of Fabbrico in the province of Reggio Emilia, and now belongs to the Argo Tractors group. The R-7500 (DT) from the 550 series is a four-wheel-drive tractor from the late 1970s to late 1980s; Italian makers use DT for doppia trazione, meaning four-wheel drive.
Read on 3 more paragraphs
The R-7500 (DT) is powered by a water-cooled four-cylinder diesel engine of 3,865 cc, producing 70 hp (51.5 kW) at 2,200 rpm with 268 Nm of torque. At a kerb weight of 3,128 kg it measures 3,830 mm in length, 1,970 mm in width and 2,740 mm in height, on a 2,460 mm wheelbase; top speed is 30 km/h.
A water-cooled four-cylinder of nearly four litres combined with four-wheel drive is built for tillage on medium to larger areas, grassland work and haulage with trailers. Four-wheel drive markedly improves traction on wet soil and gentle slopes compared with a two-wheel-drive version, though at this age it calls for particular attention to the front axle joints.
When buying a used four-wheel-drive Landini of this age, rust on the frame and hydraulic system, the condition of the radiator and water pump, and play in the four-wheel-drive joints are among the most important checks. Gearbox and brakes should be tested under load. Parts for engine and drivetrain are usually still available through dealers specialising in older Landini tractors.
Sources: SpecCodex-Register: Kennwerte des Modells Landini R-7500 (DT)
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 70 hp (51.5 kW)correct |
| Rated speed | 2,200 rpmcorrect |
| Torque | 268 Nmcorrect |
| Speed at max. torque | 1,200 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 3,865 cm³correct |
| Bore | 98.42 mmcorrect |
| Stroke | 127 mmcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,830 mmcorrect |
|---|---|
| Width | 1,970 mmcorrect |
| Height | 2,740 mmcorrect |
| Wheelbase | 2,460 mmcorrect |
| Ground clearance | 450 mmcorrect |
| Unladen weight | 3,128 kgcorrect |
Drivetrain and chassis
| Drive | rear- or four-wheel drivecorrect |
|---|---|
| Gearbox | 12 V/4 Rcorrect |
| Front tyres | 7.50-16 ASF (A: 11.2-24 AS)correct |
| Rear tyres | 16.9/14-30 AScorrect |
| Top speed | 30 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|
Where this model stands
Power-to-weight ratio: 16.5 kW/t (52 kW / 3.1 t)
Power class: Universal (40–100 hp)
Stronger than 48% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Landini R-7500 (DT) have?
The Landini R-7500 (DT) delivers 70 hp.
How much does the Landini R-7500 (DT) weigh?
The unladen weight is 3,128 kg.
What engine does the Landini R-7500 (DT) have?
4 cylinders, 3,865 cm³ displacement, Diesel.
How fast does the Landini R-7500 (DT) go?
Top speed is 30 km/h.
What are the dimensions of the Landini R-7500 (DT)?
3,830 mm × 1,970 mm × 2,740 mm.
When was the Landini R-7500 (DT) built?
Production years: 1978–1987.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 23 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
Sources: Wikibooks Traktorenlexikon (CC BY-SA 4.0) (retrieved August 2026) · Values adopted and presented in our own form; changes from the source are possible. · How we check the data
