Hitachi ZX200-3 – specifications
Series: Hitachi Hydraulic Excavator
The Hitachi Hydraulic Excavator series from Hitachi includes the ZX200-3. The engine delivers 122.3 kW, with a displacement of 5,193.1 cm³. Torque is 655.1 Nm. Rated speed is 2,000 rpm. The unladen weight is 19,800 kg. Ground clearance is 451.1 mm. The tank holds 400.1 litres. Maximum torque is reached at 1,500 rpm. The pump delivers 424.3 l/min. The hydraulic tank holds 240.4 litres. Working pressure is 343 bar. The cooling system holds 26.1 litres. The oil fill is 23.1 litres. The engine fitted is the AI-4HK1X. The Hitachi Hydraulic Excavator series covers 158 models. Rated output within it ranges from 42.4 to 481.7 kW; the ZX200-3 sits in the lower part of that range with 122.3 kW. Its immediate neighbours are the ZX210LC-6 below it with 119.3 kW and the ZX230 above it with 124.5 kW. Unladen weight within it ranges from 8,143 to 108,000 kg; here the ZX200-3 sits at the bottom of that range with 19,800 kg. 357 Hitachi models across 24 series are on record.
Build year not documented · Data origin: Directory data · sources
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Hitachi ZX – what the number and letters reveal about weight class, LC/US/W undercarriage variants and the adjustable boom option across the ZAXIS range
Hitachi codes usually start with ZX, short for the ZAXIS line. The following number places the model in an approximate operating-weight class, letters such as LC, US or W describe the undercarriage and configuration, and a dash number at the end marks the generation.
Read on 5 more paragraphs
LC marks a widened undercarriage for extra stability, US denotes ultra-short-tail models with a compact rear overhang for tight jobsites, and W marks wheeled machines. Current models run as ZAXIS-7, while older stock is still labelled -3, -5 or -6.
Alongside these sits the older EX line, such as the EX700: mechanically simpler than the ZX models, with less electronics, but built rugged for heavy continuous duty.
Alongside the one-piece monoboom, many ZX models offer a two-piece adjustable boom whose knuckle can swing sideways; this allows digging along walls or pipelines without having to square the machine itself up to them, though at somewhat lower breakout force than the rigid monoboom.
The collective entry spans small excavators from around 42 kW up to large machines above 480 kW. When buying used, check the hour meter along with the slew ring, boom-and-bucket linkage bushings and any leaks at the hydraulic cylinders.
In short: ZX plus size number plus undercarriage letter plus generation digit make up the full code, as seen on models like ZX120, ZX200 or ZX330.
Sources: SpecCodex register, model data: Hitachi Hydraulic Excavator
Technical data
Engine
| Engine model | AI-4HK1Xcorrect |
|---|---|
| Power | 122.3 kWcorrect |
| Rated speed | 2,000 rpmcorrect |
| Torque | 655.1 Nmcorrect |
| Speed at max. torque | 1,500 rpmcorrect |
| Displacement | 5,193.1 cm³correct |
| Aspiration | Turbocharged, intercooledcorrect |
| Coolant capacity | 26.1 lcorrect |
| Engine oil capacity | 23.1 lcorrect |
Dimensions and weights
| Ground clearance | 451.1 mmcorrect |
|---|---|
| Unladen weight | 19,800 kgcorrect |
Working data
| Pump flow | 424.3 l/mincorrect |
|---|---|
| Hydraulic oil capacity | 240.4 lcorrect |
| Hydraulic pressure | 343 barcorrect |
| Fuel tank capacity | 400.1 lcorrect |
Other data
| Cab height | 2,950.5 mmcorrect |
|---|
Frequently asked questions
Used listings – figures from public listings
In November 2026, speccodex recorded 9 public used-machine listings for Hitachi ZX200-3 on one platform. Asking prices ranged from €17,798 to €22,781 (median €20,318), years of manufacture between 2022 and 2025.
Operating hours stated in the listings (median) by machine age: 0–3 years: 725 h (6 listings).
Asking prices are sellers' demands, not achieved sale prices. Basis: public listings, recorded and analysed by speccodex. As of: 18 Nov 2026. Sellers usually do not state whether prices are net or gross.
Area: Machines › Construction machinery
More machines with this engine (AI-4HK1X, 10)
Where this model stands
Power-to-weight ratio: 6.2 kW/t (122 kW / 19.8 t)
Stronger than 59% of the excavators & compaction in the register — out of 1,650 models with a stated power figure.
Calculated from the documented figures above — not a rating.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 16 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Are you the manufacturer or a dealer of this machine? Check the data and add missing figures — we mark your correction as manufacturer or dealer information.
Check and complete the data →Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
