Hitachi EH3500

Series: Hitachi Rock Truck

Source: https://www.hitachi.co.jp/recruit/en/newgraduate/jm-navi/hig

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Hitachi Rock Truck series from Hitachi includes the EH3500. The engine delivers 2,053.1 hp (1,413.8 kW), has 12 cylinders. Rated speed is 1,900 rpm. The machine is 6,370 mm high. The wheelbase measures 5,641.8 mm. Ground clearance is 740.7 mm. Top speed is 55.7 km/h. The tank holds 2,839.1 litres. The cooling system holds 322.9 litres. The oil fill is 213.1 litres. The electrical system runs on 24 V. The engine fitted is the 12V-4000. Tyre size: 37,00R57 E4 Radials. The Hitachi Rock Truck series covers 24 models. Rated output within it ranges from 405.5 to 2,889.2 hp; the EH3500 sits in the upper part of that range with 2,053.1 hp. Its immediate neighbours are the EH3500ACII below it with 2,027.7 hp and the EH 4000 AC - 3 (MTU) above it with 2,534.4 hp. 357 Hitachi models across 24 series are on record. The model is listed under Mining equipment. 18 verified figures from 2 sources are on file.

Technical data

Engine

Engine model12V-4000correct
Power2,053.1 hp (1,413.8 kW)correct
Rated speed1,900 rpmcorrect
Cylinders12correct
Aspirationturbochargedcorrect
Coolant capacity322.9 lcorrect
Engine oil capacity213.1 lcorrect

Dimensions and weights

Length12,240.8correct
Height6,370 mmcorrect
Wheelbase5,641.8correct
Ground clearance740.7correct

Drivetrain and chassis

Tyre size37.00R57 E4 Radialscorrect
Top speed55.7 km/hcorrect

Working data

Fuel tank capacity2,839.1 lcorrect

Other data

System voltage24 Vcorrect

More machines with this engine (12V-4000, 3)

Frequently asked questions

How much power does the Hitachi EH3500 have?

The Hitachi EH3500 delivers 2,053 hp.

What engine does the Hitachi EH3500 have?

12 cylinders.

How fast does the Hitachi EH3500 go?

Top speed is 55.7 km/h.

What are the dimensions of the Hitachi EH3500?

12,241 mm × 6,370 mm.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
