Hitachi EH3000

Series: Hitachi Rock Truck

Source: https://www.hitachi.co.jp/recruit/en/newgraduate/jm-navi/hig

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The EH3000 from Hitachi is part of the Hitachi Rock Truck series. The engine delivers 1,901 hp (1,303.5 kW), has 12 cylinders, with a displacement of 48,751.5 cm³. Rated speed is 1,900 rpm. The wheelbase measures 5,641.8 mm. Ground clearance is 691.9 mm. Top speed is 54.7 km/h. The tank holds 2,839.1 litres. The hydraulic tank holds 755.2 litres. The cooling system holds 322.9 litres. The oil fill is 213.1 litres. The electrical system runs on 24 V. The engine fitted is the 12V-4000. Tyre size: 36,00R51 E4 Radials. The Hitachi Rock Truck series covers 24 models. Rated output within it ranges from 405.5 to 2,889.2 hp; the EH3000 sits in the upper part of that range with 1,901 hp. Its immediate neighbours are the EH1700 below it with 1,216.6 hp and the EH3500AC-3 above it with 2,027.2 hp. 347 Hitachi models across 20 series are on record. The model is listed under Mining equipment. 17 verified figures from 1 source are on file.

Technical data

Engine

Engine model12V-4000correct
Power1,901 hp (1,303.5 kW)correct
Rated speed1,900 rpmcorrect
Cylinders12correct
Displacement48,751.5 cm³correct
AspirationTurbocharged & low temperature aftercooledcorrect
Coolant capacity322.9 lcorrect
Engine oil capacity213.1 lcorrect

Dimensions and weights

Length11,551.9correct
Wheelbase5,641.8correct
Ground clearance691.9correct

Drivetrain and chassis

Tyre size36.00R51 E4 Radialscorrect
Top speed54.7 km/hcorrect
System voltage24 Vcorrect

Working data

Hydraulic oil capacity755.2 lcorrect
Fuel tank capacity2,839.1 lcorrect

Frequently asked questions

How much power does the Hitachi EH3000 have?

The Hitachi EH3000 delivers 1,901 hp.

What engine does the Hitachi EH3000 have?

12 cylinders, 48,752 cm³ displacement.

How fast does the Hitachi EH3000 go?

Top speed is 54.7 km/h.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
