Hitachi EH1700

Series: Hitachi Rock Truck

Source: https://www.lectura-specs.fr/fr/modele/machines-de-chantier/

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the EH1700, Hitachi offers a model from the Hitachi Rock Truck series. The engine delivers 1,216.6 hp (835.9 kW), with a displacement of 30,496.3 cm³. Torque is 5,084.3 Nm. Rated speed is 2,100 rpm. The machine is 10,290 mm long. The wheelbase measures 4,572 mm. Ground clearance is 862.6 mm. Top speed is 61.6 km/h. The tank holds 1,003.1 litres. Maximum torque is reached at 1,200 rpm. The hydraulic tank holds 435.3 litres. The cooling system holds 276.3 litres. The oil fill is 143.1 litres. The electrical system runs on 24 V. The engine fitted is the QST 30. Tyre size: 31/80R49 E4. The Hitachi Rock Truck series covers 24 models. Rated output within it ranges from 405.5 to 2,889.2 hp; the EH1700 sits in the lower part of that range with 1,216.6 hp. Its immediate neighbours are the EH1600 below it with 1,064.6 hp and the EH3000 above it with 1,901 hp. 347 Hitachi models across 20 series are on record. The model is listed under Mining equipment. 19 verified figures from 1 source are on file.

Technical data

Engine

Engine modelQST 30correct
Power1,216.6 hp (835.9 kW)correct
Rated speed2,100 rpmcorrect
Torque5,084.3correct
Speed at max. torque1,200 rpmcorrect
Displacement30,496.3 cm³correct
AspirationTurbocharged/Aftercooledcorrect
Coolant capacity276.3 lcorrect
Engine oil capacity143.1 lcorrect

Dimensions and weights

Length10,290correct
Height5,310 mmcorrect
Wheelbase4,572correct
Ground clearance862.6correct

Drivetrain and chassis

Gearbox typeAllison M9600A, planetary type, full automatic gearbox shift. Integral torque convertercorrect
Tyre size31/80R49 E4correct
Top speed61.6 km/hcorrect
System voltage24 Vcorrect

Working data

Hydraulic oil capacity435.3 lcorrect
Fuel tank capacity1,003.1 lcorrect

More machines with this engine (QST 30, 5)

Frequently asked questions

How much power does the Hitachi EH1700 have?

The Hitachi EH1700 delivers 1,217 hp.

What engine does the Hitachi EH1700 have?

30,496 cm³ displacement.

How fast does the Hitachi EH1700 go?

Top speed is 61.6 km/h.

What are the dimensions of the Hitachi EH1700?

10,290 mm × 5,310 mm.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
