Hanomag RD 36
Lata produkcji: 1931–1936 · Seria: Pozostałe modele
Dane techniczne
| Construction | Blockbauweise |
| Cooling | Wasserkühlung |
| Cylinders | 4 |
| Displacement cm3 | 5195 cm3 |
| Drive type | Hinterradantrieb |
| Fuel | Diesel, Gasöl, Rohöl |
| Gearbox | 3V/1R |
| Ground clearance mm | 260 mm |
| Height mm | 1950 mm |
| Length mm | 3420 mm |
| Power km | 36 KM |
| Power kw | 26.4 kW |
| Rated rpm | 1100 obr./min |
| Tires front | 800x100 Eisen/6,00-20 Luft |
| Tires rear | 1150x300 Eisen/12.75-28 Luft |
| Top speed kmh | 8 km/h |
| Units built | 611 |
| Weight kg | 2750 kg |
| Wheelbase mm | 1990 mm |
| Width mm | 1750 mm |
