Gehl 5640E Turbo
Series: Gehl Skid Steer Loader
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Gehl skid-steer loaders 1640E to 7810E and V270 – from Madison, South Dakota, Manitou since 2008: Deutz engines, the E series and the vertical-lift V models, 18 to 86 kW
Gehl of West Bend, Wisconsin, built skid-steer loaders from 1973 as a complement to its farm-machinery programme and later moved production to Madison, South Dakota, where the machines are still built today – since 2008 under the umbrella of the French Manitou group, which runs Gehl and the sister brand Mustang as its American compact-loader arms. The register shows the generations of the 1990s to 2010s: the 3635 and 3935 as older types, the 4640 to 7810 with the E upgrade from about 2008 and Turbo variants, the 1640E as the smallest and the 7810E as the largest wheeled loader of the class, and the V270 as the vertical-lift model (V for Vertical Lift), whose number gives the rated operating capacity in tens of pounds – 2,700 lb. On the four-digit types the numbers order the size class in ascending order.
Read on 3 more paragraphs
The register lists 21 versions with 17.9 to 85.8 kW from engines of 1,327 to 4,506 cm³ – Deutz F3M and F4M 2011 with turbocharged BF versions as the brand's hallmark, Yanmar in the smallest models – at rated speeds of 2,200 to 3,000 rpm.
Gehl's skid steers are known for their air-cooled and later oil-cooled Deutz engines and the hand-lever controls that many American operators prefer to joysticks; the machines share attachments and quick couplers with the market standard.
On used machines, operating hours, play in lift arm and quick coupler, the condition of drive hydraulics and chain cases, tyres and the Deutz engines, whose parts are available through Deutz dealers independently of Gehl, are what count.
Sources: Kennwerte der Modelle Gehl Kompaktlader, Gehl (Manitou Group, Hersteller)
Technical data
Engine
| Engine model | BF4M2011correct |
|---|---|
| Power | 61.1 kWcorrect |
| Rated speed | 2,500 rpmcorrect |
| Displacement | 3,113.5 cm³correct |
| Aspiration | turbochargedcorrect |
Dimensions and weights
| Wheelbase | 1,082correct |
|---|---|
| Ground clearance | 203.2correct |
Drivetrain and chassis
| Tyre size | 12.00x16.5correct |
|---|---|
| Top speed | 20 km/hcorrect |
Working data
| Pump flow | 87.1 l/mincorrect |
|---|---|
| Hydraulic oil capacity | 60.2 lcorrect |
| Fuel tank capacity | 72.3 lcorrect |
Other data
| Cab height | 2,057.4correct |
|---|---|
| System voltage | 12 Vcorrect |
More machines with this engine (BF4M2011, 8)
Frequently asked questions
How much power does the Gehl 5640E Turbo have?
The Gehl 5640E Turbo delivers 61.1 kW.
What engine does the Gehl 5640E Turbo have?
3,114 cm³ displacement.
How fast does the Gehl 5640E Turbo go?
Top speed is 20 km/h.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
