Gehl 5640E

Series: Gehl Skid Steer Loader

Source: http://www.mascus.com.tw/auction/agriculture/used-tractors/m

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The 5640E from Gehl is part of the Gehl Skid Steer Loader series. The engine delivers 61.1 kW, has 4 cylinders, with a displacement of 3,113.5 cm³. Rated speed is 2,500 rpm. The wheelbase measures 1,082 mm. Ground clearance is 203.2 mm. Top speed is 20 km/h. The tank holds 72.3 litres. The pump delivers 87.1 l/min. The hydraulic tank holds 60.2 litres. The electrical system runs on 12 V. The engine fitted is the F4M2011. Tyre size: 12,00x16,5 HD. The Gehl Skid Steer Loader series covers 21 models. Rated output within it ranges from 17.9 to 85.8 kW; the 5640E sits in the upper part of that range with 61.1 kW. Its immediate neighbours are the 5240E below it with 46.2 kW and the V270 above it with 62.6 kW. 72 Gehl models across 9 series are on record. The model is listed under Wheel loaders. 14 verified figures from 1 source are on file.

Technical data

Engine

Engine modelF4M2011correct
Power61.1 kWcorrect
Rated speed2,500 rpmcorrect
Cylinders4correct
Displacement3,113.5 cm³correct

Dimensions and weights

Wheelbase1,082correct
Ground clearance203.2correct

Drivetrain and chassis

Tyre size12.00x16.5 HDcorrect
Top speed20 km/hcorrect
System voltage12 Vcorrect

Working data

Pump flow87.1 l/mincorrect
Hydraulic oil capacity60.2 lcorrect
Fuel tank capacity72.3 lcorrect

Other data

Cab height2,057.4correct

Frequently asked questions

How much power does the Gehl 5640E have?

The Gehl 5640E delivers 61.1 kW.

What engine does the Gehl 5640E have?

4 cylinders, 3,114 cm³ displacement.

How fast does the Gehl 5640E go?

Top speed is 20 km/h.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 14 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
