Ford F250 SUPERCAB
Built: 1977 · Series: F250
More machines from model year 1977
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Ford F-250 – three-quarter-ton Super Duty pickup: XL to Platinum trims, eight- and ten-cylinder engines from 107 to 336 kW, 5.4 to 7.6-litre displacement, up to 5,035 kg gross weight
Ford has used the F-250 designation since the 1950s for the three-quarter-ton members of the F-Series; since 1999 they have formed part of the Super Duty family alongside the F-350 and F-450, with a reinforced ladder frame and optional dual rear wheels, built at the Kentucky Truck Plant in Louisville and at Ohio Assembly. The XL, XLT, Lariat and Platinum trim levels order comfort, King Ranch and the Harley-Davidson Edition are special models, and the Super Duty suffix distinguishes the reinforced frame from the plain F-250 of earlier generations.
Read on 3 more paragraphs
The register lists 64 versions with 107 to 336 kW from eight- and ten-cylinder engines of 5,400 to 7,600 cm³, unladen weights of 2,100 to 3,786 kg, gross vehicle weights of 3,500 to 5,035 kg, lengths of 5,140 to 6,700 mm and widths of 1,920 to 2,260 mm.
In North America the F-250 fills the gap between light pickups and medium-duty trucks and is used chiefly for towing – motorhomes, horse trailers, construction equipment – and in commercial fleets; its main rivals are the Chevrolet/GMC 2500 and the Ram 2500, against which Ford competes mainly on the Power Stroke diesel and towing capacity.
When buying used, check frame corrosion at the rear leaf-spring mounts and brake lines, on diesel versions the injection pump, turbocharger and exhaust aftertreatment, on the V10 Triton petrol engines the spark-plug threads and cooling system, and generally the shift behaviour of the automatic transmission; body and wear parts are widely available through the Ford parts network.
Sources: SpecCodex register, model data: Ford F-250, Ford Motor Company
Technical data
Engine
| Cylinders | 8correct |
|---|---|
| Displacement | 7,538 cm³correct |
Dimensions and weights
| Length | 6,100 mmcorrect |
|---|---|
| Width | 2,020 mmcorrect |
| Wheelbase | 3,950 mmcorrect |
| Unladen weight | 2,455 kgcorrect |
| Gross vehicle weight | 3,500 kgcorrect |
Drivetrain and chassis
| Wheels | 4correct |
|---|
Frequently asked questions
How much does the Ford F250 SUPERCAB weigh?
The unladen weight is 2,455 kg.
What is the gross vehicle weight of the Ford F250 SUPERCAB?
3,500 kg.
What engine does the Ford F250 SUPERCAB have?
8 cylinders, 7,538 cm³ displacement.
What are the dimensions of the Ford F250 SUPERCAB?
6,100 mm × 2,020 mm.
When was the Ford F250 SUPERCAB built?
Production years: 1977.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 10 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
