Farmall McCormick Farmall Cub
Built: 1947-1964 · Series: McCormick Farmall
More machines from model year 1947
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
McCormick Farmall: the International Harvester range, from the letter-series Farmalls Cub, Super A and HV of the 1940s to the export 100 to 404 series, 9 to 47 hp, four-cylinder carburettor petrol engines
McCormick Farmall is the tractor brand of International Harvester (IH), formed in 1902 in Chicago from the merger of the McCormick Harvesting Machine Company with the Deering Harvester Company. The McCormick name survived as the house brand and marked above all the Farmall tractors IH sold outside North America. This page spans the classic letter series of the 1940s and 1950s – the Cub as the smallest tractor, built at the Louisville plant, the Super A and Super AV as narrow row-crop tractors, the HV as the version with raised ground clearance for vineyards and orchards – through to the numbered export series 100 to 404, which IH built from the 1950s at its Doncaster plant in England for the European market. At IH, the letter V consistently marked the narrow vineyard and orchard version, and High Clearance the version with raised ground clearance over row crops. The engines come from International Harvester's own C series, whose type number states the displacement in cubic inches, from the C-60 in the Cub to the C-152 in the larger models.
Read on 3 more paragraphs
The register lists here 12 versions with 9 to 47 hp, all with four-cylinder petrol engines running at 1,400 to 2,000 rpm.
Farmall ranks among the most defining tractor brands of the United States, and with the introduction of the row-crop concept and the Loewy-styled letter series it marked a turning point in tractor development; as McCormick Farmall the brand carried this heritage to Europe, where IH ran its own plant at Doncaster.
On used examples, the condition of carburettor, ignition distributor and fuel tap counts, along with rust on sheet metal and radiator, the state of the belt pulley and PTO, and on the V and High Clearance versions wear on stub axles and steering; spares today run through the Case IH network and specialist Farmall dealers.
Sources: SpecCodex register, model data: McCormick Farmall, Case IH (Nachfolgemarke, Hersteller)
Technical data
Engine
| Engine make | Internationalcorrect |
|---|---|
| Engine model | C-60correct |
| Fuel | petrolcorrect |
| Power | 9 hpcorrect |
| Rated speed | 1,600 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 60 cicorrect |
| Bore | 2.625 in (66.7 mm)correct |
| Stroke | 2.75 in (69.8 mm)correct |
| Naturally aspirated | naturally aspiratedcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 99 in (2514.6 mm)correct |
|---|---|
| Width | 48 in (1219.2 mm)correct |
| Height | 63 in (1600.2 mm)correct |
| Wheelbase | 69 in (1752.6 mm)correct |
| Turning circle | 18.5 ftcorrect |
| Unladen weight | 1,430 lbcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | sliding-gear transmissioncorrect |
| Gearbox make | Internationalcorrect |
| Forward gears | 3correct |
| Reverse gears | 1correct |
| Front tyres | 4.00-12 2-ply (standard 3.00-12 2-ply)correct |
| Rear tyres | 8-24 4-ply (standard 6-24 2-ply)correct |
Working data
| Fuel tank capacity | 7.5 galcorrect |
|---|
Origin and approval
| Plant | Louisville Works, Louisville, Kentucky, USAcorrect |
|---|---|
| Units built | 224.203correct |
Other data
| Drawbar output | 8correct |
|---|---|
| List price when new | $545 (1948), $1680 (1964)correct |
| Predecessor | New modelcorrect |
| Successor | International Farmall Cubcorrect |
More machines with this engine (International C-60, 5)
Frequently asked questions
How much power does the Farmall McCormick Farmall Cub have?
The Farmall McCormick Farmall Cub delivers 9 hp.
What engine does the Farmall McCormick Farmall Cub have?
4 cylinders, Benzin.
When was the Farmall McCormick Farmall Cub built?
Production years: 1947-1964.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 35 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
