Deutz-Fahr AGROPLUS 420
Series: Agroplus
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Agroplus 420 is a tractor from Deutz‑Fahr’s Agroplus series. It is powered by a four‑cylinder engine with a displacement of 4 000 cm³ and a rated speed of 2 200 rpm. The maximum output is 95 hp (70 kW) and the peak torque is 373 Nm. With a length of 3 560 mm, a height of 2 455 mm and a wheelbase of 2 230 mm, the empty weight is 3 410 kg. The transmission provides 30 forward and 15 reverse gears, a top speed of 40 km/h and a fuel tank capacity of 90 l. The tractor belongs to the Category II power‑lift class.
A power rating of 70 kW allows the machine to pull implements up to the maximum permissible drawbar pull, while the 373 Nm torque delivers strong acceleration under load. The empty weight of 3 410 kg results in a ground pressure suitable for compact field work and offers a stable base for heavy implements. With 30 forward and 15 reverse gears, the operating speed can be finely adjusted to varying field conditions, and the 40 km/h top speed enables swift transport between work sites.
Within the Agroplus line the Agroplus 420 ranks first in power among 13 models, with only the AGROPLUS S100 at 66 kW below it. In terms of weight it ranks third of 9 models; the next lighter model is the AGROPLUS 410 DT at 3 190 kg and the next heavier is the Agroplus 420 PROFILINE at 3 550 kg. The series power range spans from 45.6 to 70 kW and the weight range from 2 630 to 4 160 kg.
Deutz-Fahr Agroplus – Compact Class From 1997 Into the 2010s, with Three- and Four-Cylinder Engines, 45.6 to 70 kW and Operating Weight from 2,750 to 4,160 kg
The Agroplus series has complemented the Deutz-Fahr range since 1997 as the compact entry class below the Agrotron series; the register lists models up to 2013. Engine output ranges from 45.6 to 70 kW, with models rated in horsepower spanning 70 to 94 hp, using three- and four-cylinder engines with displacement from 3,000 to 4,086 cm³.
Read on 3 more paragraphs
Recorded operating weight runs from 2,750 to 4,160 kg, and top speed of the listed models is 40 km/h. Later models such as the Agroplus 420 Profiline show that the series gained higher-grade equipment lines over the years.
The Agroplus series targets smaller and medium farms as well as grassland operations that need a compact, manoeuvrable tractor without the bulk of the Agrotron models. For a used model, check the emissions stage, as it differs considerably by model year.
With rated outputs from 45.6 to 70 kW, the Agroplus series falls within ISO 730 Category I to II for the rear three-point hitch, with a standard dual-speed power take-off at 540 and 1,000 revolutions per minute. Deutz-Fahr as a tractor brand belongs to the Italian SDF Group (SAME Deutz-Fahr), which is a separate company from the Cologne engine maker Deutz AG; both still supply spare parts for their respective ranges today, including for the older Agroplus model years covered here.
Sources: SpecCodex register, model data: Deutz-Fahr Agroplus, Deutz-Fahr
Technical data
Engine
| Power | 95 hp (70 kW)correct |
|---|---|
| Rated speed | 2,200 rpmcorrect |
| Torque | 373 Nmcorrect |
| Cylinders | 4correct |
| Displacement | 4,000 cm³correct |
Dimensions and weights
| Length | 3,560 mmcorrect |
|---|---|
| Height | 2,455 mmcorrect |
| Wheelbase | 2,230 mmcorrect |
| Unladen weight | 3,410 kgcorrect |
Drivetrain and chassis
| Gearbox | 30V / 15Rcorrect |
|---|---|
| Forward gears | 30correct |
| Reverse gears | 15correct |
| Top speed | 40 km/hcorrect |
Working data
| Fuel tank capacity | 90 lcorrect |
|---|
Other data
| Linkage category | Cat IIcorrect |
|---|
Where this model stands
Power-to-weight ratio: 20.5 kW/t (70 kW / 3.4 t)
Power class: Universal (40–100 hp)
Stronger than 63% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Deutz-Fahr AGROPLUS 420 have?
The Deutz-Fahr AGROPLUS 420 delivers 95 hp.
How much does the Deutz-Fahr AGROPLUS 420 weigh?
The unladen weight is 3,410 kg.
What engine does the Deutz-Fahr AGROPLUS 420 have?
4 cylinders, 4,000 cm³ displacement.
How fast does the Deutz-Fahr AGROPLUS 420 go?
Top speed is 40 km/h.
What are the dimensions of the Deutz-Fahr AGROPLUS 420?
3,560 mm × 2,455 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 16 individual figures for this model. They come from 2 recorded sources; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
