Deutz Allis 6260
Built: 1986–1990 · Series: 6.200 er- Serie
More machines from model year 1986
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Deutz-Allis 6.200 series (1985–1990) – the Deutz tractors in orange for North America: 6150 to 6275, the last digits as power step, air-cooled Deutz three- and four-cylinders of 2.8 to 4.1 litres, 33 to 54 kW
Deutz-Allis emerged in 1985 when Klöckner-Humboldt-Deutz bought the farm-equipment division of Allis-Chalmers and continued the orange tractors with its own technology – the 6200 series is the mid-range of that period: Deutz-Fahr tractors of the DX range from Cologne, painted orange and sold through the Allis-Chalmers dealer network in North America. The type logic: 6 marks the range, the following digits the power step – 6150 about 45 hp, 6240 about 55, 6250 about 60, 6260 about 65, 6265 and 6275 about 70 to 74 hp – in North America without Deutz's own DX nomenclature. The engines are Deutz's air-cooled three- and four-cylinders of the 912 and 913 series of 2.8 to 4.1 litres at 2,150 to 2,500 rpm – Deutz's hallmark, which was regarded as exotic in North America and divided customers.
Read on 3 more paragraphs
The register lists 6 versions with 32.8 to 54.4 kW from three- and four-cylinders of 2,827 to 4,086 cm³, torque from 166 to 254 Nm, unladen weights from 2,238 to 3,550 kg, lengths from 3,315 to 3,950 mm, widths from 1,643 to 2,139 mm and heights from 2,250 to 2,620 mm.
Deutz-Allis remained an episode: in 1990 KHD sold the division to its management, which founded AGCO from it and continued the brand as AGCO Allis with Cummins engines; the 6200s are the Deutz tractors with the rarest badge.
On used tractors, operating hours, the condition of cooling blower and cylinder fins (overheating when fouled), injection pump, clutch and gearbox, hydraulics and sheet metal count; parts run through Deutz (engine) and AGCO (machine).
Sources: SpecCodex register, model data: Deutz-Allis 6.200er-Serie, Deutz-Allis (Wikipedia)
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 58 hp (42.7 kW)correct |
| Rated speed | 2,500 rpmcorrect |
| Torque | 195 Nmcorrect |
| Speed at max. torque | 1,550 rpmcorrect |
| Cylinders | 3correct |
| Displacement | 3,064 cm³correct |
| Bore | 102.11 mmcorrect |
| Stroke | 124.97 mmcorrect |
| Cooling | air-cooledcorrect |
Dimensions and weights
| Length | 3,640 mmcorrect |
|---|---|
| Width | 2,139 mmcorrect |
| Height | 2,480 mmcorrect |
| Wheelbase | 2,012 mmcorrect |
| Ground clearance | 457 mmcorrect |
| Unladen weight | 2,930 kgcorrect |
Drivetrain and chassis
| Drive | rear- or four-wheel drivecorrect |
|---|---|
| Gearbox | 8 V/4 R or 16 V/8 Rcorrect |
| Front tyres | 7.50-16 ASF (4 WD: 11.2-24 AS)correct |
| Rear tyres | 16.9 R 30 AScorrect |
| Top speed | 30 km/hcorrect |
Working data
| Fuel tank capacity | 75 lcorrect |
|---|
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|
Other data
| Linkage category | Cat IIcorrect |
|---|---|
| PTO speed | 540/1000 rpmcorrect |
Where this model stands
Power-to-weight ratio: 14.6 kW/t (43 kW / 2.9 t)
Power class: Universal (40–100 hp)
Stronger than 40% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Deutz Allis 6260 have?
The Deutz Allis 6260 delivers 58 hp.
How much does the Deutz Allis 6260 weigh?
The unladen weight is 2,930 kg.
What engine does the Deutz Allis 6260 have?
3 cylinders, 3,064 cm³ displacement, Diesel.
How fast does the Deutz Allis 6260 go?
Top speed is 30 km/h.
What are the dimensions of the Deutz Allis 6260?
3,640 mm × 2,139 mm × 2,480 mm.
When was the Deutz Allis 6260 built?
Production years: 1986–1990.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
