Daimler Benz LA 1113 – specifications
Built: 1982 · Series: LA
The LA 1113 from Daimler Benz is part of the LA series. Production: 1982. The engine has 6 cylinders, with a displacement of 5,638 cm³. The vehicle is 7,250 mm long and 2,500 mm wide. The unladen weight is 7,380 kg. The wheelbase measures 4,180 mm. Top speed is 89 km/h. The gross vehicle weight is 11,000 kg. The vehicle runs on 6 wheels. The LA series covers 5 models. Unladen weight within it ranges from 5,255 to 7,380 kg; the LA 1113 sits at the top of that range with 7,380 kg. Its immediate neighbours are the LA 1113 B below it with 6,635 kg. Gross vehicle weight within it ranges from 8,500 to 11,000 kg; here the LA 1113 sits at the top of that range with 11,000 kg. 131 Daimler Benz models across 11 series are on record.
Data for the version built 1982 · Data origin: Official register · sources
More machines from model year 1982
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Daimler-Benz LA – four-wheel-drive trucks of the Kurzhauber generation: LA 911 and LA 1113, 5.1 to 5.6-litre displacement, gross vehicle weight 8,500 to 11,000 kg
At Daimler-Benz, LA denotes a truck with four-wheel drive and marks the off-road-capable variants within the classic short-nose Kurzhauber ranges of the 1960s and 1970s, alongside the road-going L models. The type designation followed Mercedes's system of the time: the first digits give the weight class in hundreds of kilograms of gross vehicle weight, the last two the engine output in PS divided by ten – LA 911 thus denotes roughly 9,000 kg gross weight and about 110 PS, LA 1113 roughly 11,000 kg and about 130 PS. The suffixes B and BMA denote equipment or body variants within these types.
Read on 3 more paragraphs
The register lists 5 versions here with displacements from 5,070 to 5,638 cm³, four to six cylinders, kerb weights from 5,255 to 7,380 kg, gross vehicle weights from 8,500 to 11,000 kg, lengths from 6,400 to 7,250 mm and widths from 2,320 to 2,500 mm.
As a chassis for tippers, flatbeds and fire-service bodies with four-wheel drive, the short-nose LA models shaped construction and municipal use as well as export to countries with unpaved roads, before Mercedes-Benz replaced them with cab-over ranges.
On used examples, corrosion on the chassis frame and cab, the condition of the transfer case and front axle on the four-wheel-drive models, and the condition of the brake system and body all matter; engine and chassis parts are available through specialist Mercedes classic-vehicle workshops.
Sources: SpecCodex register, model data: Daimler-Benz LA, Mercedes-Benz Trucks
Technical data
Engine
| Cylinders | 6correct |
|---|---|
| Displacement | 5,638 cm³correct |
Dimensions and weights
| Length | 7,250 mmcorrect |
|---|---|
| Width | 2,500 mmcorrect |
| Wheelbase | 4,180 mmcorrect |
| Unladen weight | 7,380 kgcorrect |
| Gross vehicle weight | 11,000 kgcorrect |
Drivetrain and chassis
| Wheels | 6correct |
|---|---|
| Top speed | 89 km/hcorrect |
Frequently asked questions
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 11 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Are you the manufacturer or a dealer of this machine? Check the data and add missing figures — we mark your correction as manufacturer or dealer information.
Check and complete the data →Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
Other models in this series
Sources: RDW — Dutch national vehicle register (retrieved August 2026) · Data sources and cross-checks
