Cummins V5.0 200
Built: 2017-2018 · Series: Other models
More machines from model year 2017
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Cummins – other heavy-duty highway engines: the collective page of the B, ISB, ISV and ISX12 ranges outside the named models, diesel and natural-gas variants, 200 to 500 kW, model years 2013 to 2026
Cummins Inc. of Columbus, Indiana, founded in 1919, is one of the largest independent makers of diesel and gas engines for heavy commercial vehicles worldwide. This page gathers the on-highway engines the register could not assign to a named range, from the mid-duty B6.7N range through the ISB and ISV5.0 models to the heavy ISX12 range for long-haul trucking, plus the natural-gas variants marked with a G, ISBG and ISLG; the ISB, ISL and ISX prefixes traditionally denote different Cummins build sizes and duty classes.
Read on 3 more paragraphs
The register lists here 67 versions with 200 to 500 kW rated output at 1,761 to 3,200 rpm, model years 2013 to 2026, with torques from 520 to 1,700 Nm at 1,000 to 1,600 rpm. Among the diesel versions direct injection (54) prevails over electronic direct injection (7), while six versions running on compressed or liquefied natural gas use throttle-body injection, typical of spark-ignited gas engines.
The ISX12 range is Cummins' flagship for long-haul tractor units, while the B6.7N engines drive medium-duty trucks and coaches; the ISBG and ISLG natural-gas variants target emission-sensitive fleets such as city buses and refuse trucks. In the North American heavy highway-engine market, Cummins competes chiefly with Detroit Diesel, PACCAR MX and the Volvo and Mack engines.
On a used purchase, mileage and service records count, on the diesel variants the condition of the injection pump or injectors and turbocharger, on the gas engines the condition of the gas system and spark plugs in place of a glow or pre-heat system, and depending on model year the exhaust aftertreatment with particulate filter and SCR catalyst; spare parts run through the dense Cummins dealer network.
Sources: SpecCodex register, model data: Cummins (weitere Heavy-Duty-Straßenmotoren), Cummins Inc. (manufacturer)
Technical data
Engine
| Engine code | 4946; FR80030correct |
|---|---|
| Engine family | JCEXH0305VAAcorrect |
| Engine families | JCEXH0305VAA; HCEXH0305VAAcorrect |
| Fuel | 7-15 ppm ultra low sulfur dieselcorrect |
| Rated output | 149.1 kW (= 200 hp)correct |
| Rated speed | 3,200 rpmcorrect |
| Maximum torque | 520 ft·lbfcorrect |
| Speed at max. torque | 1,600 rpmcorrect |
| Displacement | 5,000 cm³correct |
| Displacement | 5 lcorrect |
| Operating cycle | dieselcorrect |
| Injection | direct injectioncorrect |
| Aspiration | turbochargedcorrect |
Origin and approval
| Version | 4946; FR80030correct |
|---|---|
| Built from | 2017correct |
| Built to | 2018correct |
| Model year from | 2017correct |
| Model year to | 2018correct |
| Sales region | USA certificationcorrect |
Other data
| Application | Vocationalcorrect |
|---|
Frequently asked questions
How much power does the Cummins V5.0 200 have?
The Cummins V5.0 200 delivers 149 kW.
What engine does the Cummins V5.0 200 have?
5,000 cm³ displacement, 7-15 ppm ultra low sulfur diesel.
When was the Cummins V5.0 200 built?
Production years: 2017-2018.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 23 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
Other models in this series
B6.7N
B6.7N 200
B6.7N 220
B6.7N 240
ISB 280H
ISB 280HS
ISBG
ISLG
ISV5.0 200
ISV5.0 220
ISV5.0 250
ISV5.0 275
Sources: US EPA — engine certification data (retrieved August 2026) · How we check the data
Diesel engine in 3D section
Turn the model, look inside and click an assembly — each one is explained.
Parts for this engine (26)
Manufacturer part numbers from the official EPA documentation. No prices or availability — those come from the supplier.
| Teilenummer | Bezeichnung | Hersteller |
|---|---|---|
| 4384812 | Aftertreatment Temperature Sensor | Cummins |
| 4353050 | Ammonia Slip Catalyst | Cummins |
| 4326617 | Camshaft Position Sensor | Cummins |
| 2897333 | Charge Air Cooler Temperature | Cummins |
| 2897332 | Compressor Inlet Temperature | Cummins |
| 4954905 | Coolant Temperature Sensor;Coolant Temp Sensor;Coolant Temperature Sensor;Engine Out NOx Sensor 2;Coolant Temperature Sensor;Oil Temperature Sensor;Oil Temperature Sensor;Coolant Temperature Sensor;Coolant temp sensor | Cummins |
| 5309345 | Diesel Oxidation Catalyst | Cummins |
| 5309346 | Diesel Particulate Filter | Cummins |
| 2871960 | Diesel Particulate Filter Pressure | Cummins |
| 4307101 | Aftertreatment Temperature Sensor | Cummins |
| 4391018 | EGR Cooler | Cummins |
| 5472825 | EGR Cooler | Cummins |
| 4928594 | Exhaust Manifold Pressure;EGR Orifice Pressure Sensor;EGR pressure sensor | Cummins |
| 4359654 | EGR Valve | Cummins |
| 4390648 | Engine Control Module | Cummins |
| 4326870 | Engine Out NOx Sensor 1;Engine Out NOx Sensor | Cummins |
| 4327230 | Engine Crankshaft;Engine Crankshaft;Engine Cam;Engine Speed Sensor | Cummins |
| 2872858 | EGR Out Temperature Sensor;Intake Manifold Temp Sensor;EGR Out Temperature Sensor;EGR Out Temperature Sensor;Intake Manifold Temp Sensor;EGR temp sensor | Cummins |
| 4384138 | Exhaust Gas Recirculation Pressure | Cummins |
| 4378552 | Fuel Injection Pump | Cummins |
| 4325543 | Fuel Injector | Cummins |
| 2884597 | Fuel Pressure | Cummins |
| 4326872¿ | NOx Sensor Selective Catalytic Reduction | Cummins |
| 4307100 | Aftertreatment Temperature Sensor | Cummins |
| 5359077 | Turbocharger | Cummins |
| 4378341 | Turbocharger Speed Sensor | Cummins |
Quelle: EPA HD Engines 2015–Present
