Champion 740
Series: Champion Motor Grader
The Champion 740 belongs to the Champion Motor Grader series. The engine delivers 156.6 kW, has 6 cylinders, with a displacement of 10,800.7 cm³. The engine comes from Cummins. Rated speed is 2,100 rpm. The machine is 8,638 mm long and 2,542 mm wide. The wheelbase measures 6,248.4 mm. Ground clearance is 640.1 mm. The tank holds 378.5 litres. Maximum torque is reached at 1,300 rpm. The hydraulic tank holds 90.1 litres. Working pressure is 172.4 bar. The cooling system holds 48.1 litres. The engine fitted is the M11. Tyre size: 14,00 * 24. G-2. The Champion Motor Grader series covers 12 models. Rated output within it ranges from 104.4 to 156.6 kW; the 740 sits at the top of that range with 156.6 kW. Its immediate neighbours are the 780A below it with 149.1 kW. 12 Champion models are on record. The model is listed under Motor graders. 18 verified figures from 1 source are on file.
Technical data
Engine
| Engine make | Cumminscorrect |
|---|---|
| Engine model | M11correct |
| Power | 156.6 kWcorrect |
| Rated speed | 2,100 rpmcorrect |
| Speed at max. torque | 1,300 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 10,800.7 cm³correct |
| Aspiration | turbochargedcorrect |
| Coolant capacity | 48.1 lcorrect |
Dimensions and weights
| Length | 8,638correct |
|---|---|
| Width | 2,542correct |
| Wheelbase | 6,248.4correct |
| Ground clearance | 640.1correct |
Drivetrain and chassis
| Gearbox type | powershift transmissioncorrect |
|---|---|
| Tyre size | 14.00 * 24, G-2correct |
Working data
| Hydraulic oil capacity | 90.1 lcorrect |
|---|---|
| Hydraulic pressure | 172.4correct |
| Fuel tank capacity | 378.5 lcorrect |
Frequently asked questions
How much power does the Champion 740 have?
The Champion 740 delivers 157 kW.
What engine does the Champion 740 have?
6 cylinders, 10,801 cm³ displacement.
What are the dimensions of the Champion 740?
8,638 mm × 2,542 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
