Champion 710A

Series: Champion Motor Grader

Source: https://www.champion.com/pages/sweats-hq

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the 710A, Champion offers a model from the Champion Motor Grader series. The engine delivers 104.4 kW, has 6 cylinders, with a displacement of 5,901 cm³. The engine comes from Cummins. Rated speed is 2,200 rpm. The wheelbase measures 6,096 mm. Ground clearance is 609.6 mm. The tank holds 378.5 litres. Maximum torque is reached at 1,600 rpm. The hydraulic tank holds 90.1 litres. Working pressure is 172.4 bar. The cooling system holds 44.3 litres. The engine fitted is the 6B5,9. Tyre size: 13,00 * 24. G-2. The Champion Motor Grader series covers 12 models. Rated output within it ranges from 104.4 to 156.6 kW; the 710A sits at the bottom of that range with 104.4 kW. Its immediate neighbours are the 750A above it with 149.1 kW. 12 Champion models are on record. The model is listed under Motor graders. 18 verified figures from 1 source are on file.

Technical data

Engine

Engine makeCumminscorrect
Engine model6B5.9correct
Power104.4 kWcorrect
Rated speed2,200 rpmcorrect
Speed at max. torque1,600 rpmcorrect
Cylinders6correct
Displacement5,901 cm³correct
Aspirationturbochargedcorrect
Coolant capacity44.3 lcorrect

Dimensions and weights

Length8,458.2correct
Width2,490.2correct
Wheelbase6,096correct
Ground clearance609.6correct

Drivetrain and chassis

Gearbox typepowershift transmissioncorrect
Tyre size13.00 * 24, G-2correct

Working data

Hydraulic oil capacity90.1 lcorrect
Hydraulic pressure172.4correct
Fuel tank capacity378.5 lcorrect

Frequently asked questions

How much power does the Champion 710A have?

The Champion 710A delivers 104 kW.

What engine does the Champion 710A have?

6 cylinders, 5,901 cm³ displacement.

What are the dimensions of the Champion 710A?

8,458 mm × 2,490 mm.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 18 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →

Other models in this series

720A

730A

740

740A

750A

780A

C60C

C66C

C70C

C80C

C86C
