Case 885 (DT) – specifications
Built: 1985–1990 · Series: 85 er-Baureihe
With the 885 (DT), Case offers a model from the 85er series. Production: 1985–1990. The engine delivers 83 hp (61 kW), has 4 cylinders, with a displacement of 4,389 cm³. Torque is 296 Nm. Rated speed is 2,400 rpm. The machine is 3,180 mm long, 1,760 mm wide and 2,400 mm high. The unladen weight is 3,014 kg. The wheelbase measures 2,235 mm. Ground clearance is 460 mm. Top speed is 30 km/h. Transmission: 8 V/4 R or 16 V/8 R. The engine is water-cooled. Tyres: front 7.50-18 ASF (DT: 12.4 R 24 AS), rear 18.4 R 30 AS (DT: 13.6 R 38 AS). The fuel is diesel. The bore measures 100 mm. The stroke is 139.7 mm. The compression ratio is 15.1:1. Maximum torque is reached at 1,300 rpm. Construction: unit construction (no separate frame). The 85 er-Baureihe series covers 5 models. Rated output within it ranges from 52 to 83 hp; the 885 (DT) sits at the top of that range with 83 hp. Its immediate neighbours are the 785 (DT) below it with 77 hp. Unladen weight within it ranges from 2,358 to 3,014 kg; here the 885 (DT) sits at the top of that range with 3,014 kg. 636 Case models across 32 series are on record.
Data for the version built 1985–1990 · Data origin: Reference work (Wikipedia/Wikibooks) · sources
More machines from model year 1985
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Case International 85 series (1985–1990) – the Doncaster tractors with David Brown heritage: 485 to 885, the final digits 85 as series, the first digit as size class, DT for four-wheel drive
The 85 series was the first range to come to market in red as Case International after the merger of Case and International Harvester in 1985 – the successors to the David Brown 94 range from Meltham and the IH 84 range from Doncaster, merged into one range Case IH built in Doncaster, England. The type logic: the final digits 85 mark the series, the first digit orders the size in ascending order – 485 about 50 hp, 585 about 60, 685 about 70, 785 about 75, 885 about 85 hp – DT four-wheel drive. The engines are the David Brown three- and four-cylinders of 2.9 to 4.4 litres at 2,180 to 2,400 rpm that the 85s took over from the 94s, with the gearboxes with Hydra-Shift powershift step and the Synchro shuttle; the cab was David Brown's Q-Cab, regarded as quiet.
Read on 3 more paragraphs
The register lists 5 versions with 38.2 to 61 kW from three- and four-cylinders of 2,933 to 4,389 cm³, torque from 164 to 296 Nm, unladen weights from 2,358 to 3,014 kg, lengths from 3,180 to 3,747 mm, widths from 1,760 to 1,870 mm and heights from 2,310 to 2,649 mm.
The 85s are numerous in the fleets of Britain, Ireland, Scandinavia and Germany and the last tractors with David Brown engine; in 1990 the 95s followed and afterwards the 3200s and 4200s with IH engines from Neuss.
On used tractors, operating hours, engine condition and injection pump, clutch, gearbox and Hydra-Shift, hydraulics, four-wheel-drive clutch on DT models, cab and sheet metal count; parts run through Case IH and David Brown specialists.
Sources: SpecCodex register, model data: Case International 85er-Baureihe, Case IH (manufacturer)
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 83 hp (61 kW)correct |
| Rated speed | 2,400 rpmcorrect |
| Torque | 296 Nmcorrect |
| Speed at max. torque | 1,300 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 4,389 cm³correct |
| Bore | 100 mmcorrect |
| Stroke | 139.7 mmcorrect |
| Compression ratio | 15.1correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,180 mmcorrect |
|---|---|
| Width | 1,760 mmcorrect |
| Height | 2,400 mmcorrect |
| Wheelbase | 2,235 mmcorrect |
| Ground clearance | 460 mmcorrect |
| Unladen weight | 3,014 kgcorrect |
Drivetrain and chassis
| Drive | rear- or four-wheel drivecorrect |
|---|---|
| Gearbox | 8 V/4 R or 16 V/8 Rcorrect |
| Front tyres | 7.50-18 ASF (DT: 12.4 R 24 AS)correct |
| Rear tyres | 18.4 R 30 AS (DT: 13.6 R 38 AS)correct |
| Top speed | 30 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|
Frequently asked questions
Where this model stands
Power-to-weight ratio: 20.2 kW/t (61 kW / 3 t)
Power class: Universal (40–100 hp)
Stronger than 57% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 24 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Are you the manufacturer or a dealer of this machine? Check the data and add missing figures — we mark your correction as manufacturer or dealer information.
Check and complete the data →Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
