Case IH MAXXUM 140 LIMITED (2007-2011) 4WD – specifications
Series: Maxxum
Build year not documented · Data origin: Directory data · sources
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Maxxum 140 Limited is a tractor from the second generation of the Case IH Maxxum series. It was produced from 2007 to 2011 and is positioned as a mid-range model below the Puma series. The vehicle is equipped with a six-cylinder engine with a displacement of 6,700.7 cm³. The all-wheel-drive configuration ensures even power distribution to both axles, improving traction under demanding soil conditions.
The tractor is powered by a Case IH engine with a turbocharger and charge-air cooling. This technology enables efficient combustion and maintains stable engine temperatures even under high load. The powershift transmission offers 16 forward and 16 reverse gears, allowing flexible speed adjustment to various working speeds without engaging the clutch. The lift capacity of 4,364 kg determines the maximum rear attachment load, which is relevant for heavy implements such as plows or mowers. The width of 2,170.2 mm influences the track width and thus the stability when driving on uneven terrain.
Within the recorded data of the Maxxum series, the lift capacity of this model lies in the upper range of the spectrum from 3,406 to 7,864 kg. The series includes models with displacements between 3,920 and 7,480 cm³ and outputs from 66 to 170 kW. The Maxxum 140 Limited utilizes this technical basis for tasks requiring high drawbar pull and stable handling. The cab height of 2,900.2 mm provides sufficient space for the operator, while the overall dimensions are designed for good maneuverability in the field.
Case IH Maxxum – One Name for Two Tractor Generations Since 1989, with Four- and Six-Cylinder Engines, 66 to 170 kW and Operating Weight from 4,573.6 to 7,980 kg
Case IH first used the Maxxum name in 1989 for its 5100 series, then revived it in 2007 for a second generation positioned as a mid-range model below the Puma line. These two eras explain the wide spread of the register data: four- and six-cylinder engines with displacement from 3,920 to 7,480 cm³, output from 66 to 170 kW, and PTO ratings from 90 to 120 hp among the recorded models.
Read on 3 more paragraphs
Recorded operating weight ranges from 4,573.6 to 7,980 kg, wheelbase from 2,345 to 2,664 mm, and hydraulic lift capacity from 3,406 to 7,864 kg. Top speed spans from 25 km/h on older mechanical versions to 50 km/h on newer CVX-equipped variants.
For buyers, identifying the generation matters most: the 1990s 5100 series is a fundamentally different tractor from the Maxxum built since 2007, which in the current line-up sits above the Farmall range and below the Puma.
With rated outputs from 66 to 170 kW, the Maxxum spans ISO 730 Category II to III for the rear three-point hitch across both generations, with a standard dual-speed power take-off at 540 and 1,000 revolutions per minute. Case IH remains part of the CNH Industrial group today, so spare parts for the engine, gearbox and hydraulics of this series run through the existing Case IH parts network, whichever generation of Maxxum happens to be involved.
Sources: SpecCodex register, model data: Case IH Maxxum, Case IH
Technical data
Engine
| Engine make | Case IHcorrect |
|---|---|
| Engine model | Maxxum 140 Limited (2007-2011)correct |
| Cylinders | 6correct |
| Displacement | 6,700.7 cm³correct |
| Aspiration | Turbocharged with air-to-air intercoolercorrect |
Dimensions and weights
| Width | 2,170.2 mmcorrect |
|---|
Drivetrain and chassis
| Gearbox type | Semi powershift transmissioncorrect |
|---|---|
| Forward gears | 16correct |
| Reverse gears | 16correct |
Working data
| Lifting capacity | 4,364 kgcorrect |
|---|
Other data
| Cab height | 2,900.2 mmcorrect |
|---|
Frequently asked questions
What engine does the Case IH MAXXUM 140 LIMITED (2007-2011) have?
6 cylinders, 6,701 cm³ displacement.
How much does the rear linkage of the Case IH MAXXUM 140 LIMITED (2007-2011) lift?
The rear linkage lifts 4,364 kg.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 11 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
