Case IH FARMALL 45C SERIES II 4WD – specifications
Series: Farmall
Build year not documented · Data origin: Reference work (Wikipedia/Wikibooks), Directory data · sources
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Case IH Farmall 45C Series II is a compact four-wheel-drive tractor from the current Farmall range. As a variant in the C equipment class, it is positioned in the more comfortable version of the series, distinguished from simpler entry-level models by an improved cab and hydraulics. The range itself encompasses a broad spectrum of compact to mid-sized utility tractors designed for various agricultural and municipal applications.
The tractor is powered by a three-cylinder turbocharged engine with a displacement of 1,881.2 cm³, delivering 45 hp (33.5 kW) at 2,600 rpm. The transmission offers 16 forward and 16 reverse gears, allowing for flexible adaptation to different working speeds in the field. With an unladen weight of 1,710 kg and a lifting capacity of 1,120 kg, the machine is suitable for attaching various implements, while the PTO speed of 540 rpm ensures compatibility with common attachments. The width of 1,755.1 mm and height of 2,500 mm define the external dimensions for transport and passage through barns.
In the power hierarchy of the range, the Farmall 45C Series II ranks 22nd out of 32 recorded models with 33.5 kW. It is positioned directly above the Farmall 40B with 30.6 kW and below the Farmall 50B with 35 kW, with its output practically matching that of the Farmall 45 model. Regarding weight, it ranks 22nd out of 25 models at 1,710 kg, positioned between the lighter Farmall 35A at 1,391 kg and the heavier FARMALL 40C at 1,755 kg. The total power range of the series spans from 21 to 86 kW.
Case IH Farmall – A, C and U: the compact utility class and what the letters mean
At Case IH, Farmall is today the family of compact and mid-size utility tractors – the name goes back to International Harvester's Farmall line, which shaped the row-crop tractor from the 1920s onward. Today's Farmalls share only the name with the historic models; they span the range from a yard-loader substitute to an all-rounder for grassland, municipal work and specialty crops.
Read on 3 more paragraphs
The number in the name follows power, the letter the trim level: A marks the simply equipped entry version, C the more comfortable version with a better cab and hydraulics, U the utility class with more transmission options; suffixes such as PRO or EP denote equipment packages, Flatdeck a flat platform without a transmission tunnel. The engines come from within the group (FPT Industrial), mostly with three or four cylinders.
In the register the models run from 21 to 86 kW with 1,501 to 4,502 cm³ of displacement; PTO output lies between 25 and 90 hp, the rear linkage lifts 650 to 3,266 kg, and unladen weight ranges from about 1,154 to 4,740 kg. That spread shows Farmall is not a single series but a class with several size steps.
Buyers of used machines should check the trim level carefully – an A and a C with the same number differ clearly in transmission, hydraulic capacity and cab – and look at the service history of the exhaust aftertreatment on younger model years.
Sources: SpecCodex register, model data: Case IH Farmall, Case IH Traktorenprogramm (manufacturer), Farmall (Wikipedia)
Technical data
Engine
| Engine make | LS Mtroncorrect |
|---|---|
| Engine model | L3C19-Tcorrect |
| Power | 45 hp (33.5 kW)correct |
| Rated speed | 2,600 rpmcorrect |
| Cylinders | 3correct |
| Displacement | 1,881.2 cm³correct |
| Aspiration | turbochargedcorrect |
Dimensions and weights
| Width | 1,755.1 mmcorrect |
|---|---|
| Height | 2,500 mmcorrect |
| Wheelbase | 1,862.3 mmcorrect |
| Unladen weight | 1,710 kgcorrect |
Drivetrain and chassis
| Gearbox type | 4 synchro speeds in 4 non-synchro rangescorrect |
|---|---|
| Forward gears | 16correct |
| Reverse gears | 16correct |
Working data
| Lifting capacity | 1,120 kgcorrect |
|---|---|
| Fuel tank capacity | 40 lcorrect |
Other data
| Cab height | 2,370.1 mmcorrect |
|---|---|
| PTO speed | 540correct |
More machines with this engine (LS Mtron L3C19-T, 4)
Where this model stands
Power-to-weight ratio: 19.6 kW/t (34 kW / 1.7 t)
Power class: Universal (40–100 hp)
Stronger than 30% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Case IH FARMALL 45C SERIES II have?
The Case IH FARMALL 45C SERIES II delivers 45 hp.
How much does the Case IH FARMALL 45C SERIES II weigh?
The unladen weight is 1,710 kg.
What engine does the Case IH FARMALL 45C SERIES II have?
3 cylinders, 1,881 cm³ displacement.
How much does the rear linkage of the Case IH FARMALL 45C SERIES II lift?
The rear linkage lifts 1,120 kg.
What are the dimensions of the Case IH FARMALL 45C SERIES II?
1,755 mm × 2,500 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
