Case IH FARMALL 105U (2013-2015) 4WD – specifications
Series: Farmall
Build year not documented · Data origin: Directory data · sources
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Farmall 105U is a universal tractor from the Case IH brand, produced within the Farmall series between 2013 and 2015. As a four-wheel-drive variant, this model is positioned in the universal class, designated by the suffix U. The Farmall series comprises compact and mid-range tractors designed for various agricultural applications. The name historically derives from the Farmall line, although the current generation pursues technically independent concepts. The number in the model name corresponds to the power class, while the letter defines the specific equipment level.
The tractor is powered by a Case IH FPT engine with four cylinders and a displacement of 3,400.3 cm³. Turbocharging with air-to-air intercooling ensures efficient combustion and sufficient torque in the low-speed range. The 4-speed synchronized transmission provides a total of 12 forward and 12 reverse gears, allowing for fine gradation of travel speeds for different field operations. With a lifting capacity of 2,900 kg, the vehicle can support heavy implements such as front loaders or rear-mounted machinery. The width of 2,108.2 mm and the wheelbase of 2,350 mm define the basic vehicle dimensions for transport and maneuverability in the field.
Within the Farmall series, the Farmall 105U occupies a position in the mid-power range. The series covers a broad spectrum, ranging from a simple loader replacement to an all-rounder for grassland, municipal services, and specialty crops. The universal class with the U suffix is characterized by more transmission options compared to simpler entry-level variants. This model is therefore particularly suitable for tasks requiring high variability in speed selection and robust hydraulic performance. It functions as a versatile work tool for operations that wish to cover both arable farming and transport tasks with a single vehicle.
Case IH Farmall – A, C and U: the compact utility class and what the letters mean
At Case IH, Farmall is today the family of compact and mid-size utility tractors – the name goes back to International Harvester's Farmall line, which shaped the row-crop tractor from the 1920s onward. Today's Farmalls share only the name with the historic models; they span the range from a yard-loader substitute to an all-rounder for grassland, municipal work and specialty crops.
Read on 3 more paragraphs
The number in the name follows power, the letter the trim level: A marks the simply equipped entry version, C the more comfortable version with a better cab and hydraulics, U the utility class with more transmission options; suffixes such as PRO or EP denote equipment packages, Flatdeck a flat platform without a transmission tunnel. The engines come from within the group (FPT Industrial), mostly with three or four cylinders.
In the register the models run from 21 to 86 kW with 1,501 to 4,502 cm³ of displacement; PTO output lies between 25 and 90 hp, the rear linkage lifts 650 to 3,266 kg, and unladen weight ranges from about 1,154 to 4,740 kg. That spread shows Farmall is not a single series but a class with several size steps.
Buyers of used machines should check the trim level carefully – an A and a C with the same number differ clearly in transmission, hydraulic capacity and cab – and look at the service history of the exhaust aftertreatment on younger model years.
Sources: SpecCodex register, model data: Case IH Farmall, Case IH Traktorenprogramm (manufacturer), Farmall (Wikipedia)
Technical data
Engine
| Engine make | Case IH FPTcorrect |
|---|---|
| Engine model | 3.4 Lcorrect |
| Cylinders | 4correct |
| Displacement | 3,400.3 cm³correct |
| Aspiration | Turbocharged, air-to-air aftercooledcorrect |
Dimensions and weights
| Width | 2,108.2 mmcorrect |
|---|---|
| Wheelbase | 2,350 mmcorrect |
Drivetrain and chassis
| Gearbox type | 4 synchromesh gearbox gears, 3 non-synch rangescorrect |
|---|---|
| Forward gears | 12correct |
| Reverse gears | 12correct |
Working data
| Lifting capacity | 2,900 kgcorrect |
|---|
Other data
| Cab height | 2,612.1 mmcorrect |
|---|
Frequently asked questions
More machines with this engine (Case IH FPT 3.4 L, 10)
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
