Burg BPA 16

Built: 1968-1972 · Series: BPA

More machines from model year 1968

Source: autoline.ua

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The BPA 16 from Burg is part of the BPA series. Production: 1968-1972. The vehicle is 9,350 mm long and 2,500 mm wide. The unladen weight is 19,200 kg. The wheelbase measures 4,900 mm. Top speed is 100 km/h. The gross vehicle weight is 20,000 kg. The BPA series covers 134 models. Unladen weight within it ranges from 2,800 to 19,200 kg; the BPA 16 sits at the top of that range with 19,200 kg. Its immediate neighbours are the BPA 18-27 OBXXX below it with 10,610 kg. Gross vehicle weight within it ranges from 11,300 to 45,000 kg; here the BPA 16 sits in the lower part of that range with 20,000 kg. 981 Burg models across 11 series are on record.

Burg BPA – the type series of the Dutch tank and silo trailer builder Burg: 134 versions with B.P.A. codes, unladen weights 2,800 to 19,200 kg, permissible gross weights 11,300 to 45,000 kg

BPA is one of the type series of the Dutch trailer builder Burg, best known for tank and silo semi-trailers. In the register, the series consistently appears with the code B.P.A. or BPA, followed by two number groups and, in part, a letter code such as ACXXX, ORNXX, RGZXX or TCZXX – recognisably a combination of an axle-load or payload figure and an internal equipment or variant identifier whose exact meaning Burg does not publish.

Read on 3 more paragraphs

The register lists 134 versions with unladen weights from 2,800 to 19,200 kg and permissible gross weights from 11,300 to 45,000 kg. Lengths are recorded for 65 of the 134 vehicles and range from 8,080 to 14,260 mm, width for all 134 versions from 2,200 to 2,600 mm.

Within the Burg range, BPA stands alongside series with tipper and flatbed bodies as the designation for tank and silo transport; the narrow width span of just 400 mm points to a largely standardised vehicle width across the series. As semi-trailers with a kingpin, these vehicles fall into class O4 for trailers above 10 tonnes, which need a category CE licence to tow.

For a used tank or silo trailer of this series, check the tightness of the vessel, manhole covers and outlet fittings, corrosion on vessel supports and the frame, the condition of axles and the EBS braking system, and the function of the air suspension. For silo versions, the condition of the unloading and compressor system also matters; a complete inspection history is important, since parts for the BPA series are usually only available through the manufacturer itself.

Sources: SpecCodex register, model data: Burg BPA

Technical data

Dimensions and weights

Length9,350 mmcorrect
Width2,500 mmcorrect
Wheelbase4,900 mmcorrect
Unladen weight19,200 kgcorrect
Gross vehicle weight20,000 kgcorrect

Drivetrain and chassis

Top speed100 km/hcorrect

Frequently asked questions

How much does the Burg BPA 16 weigh?

The unladen weight is 19,200 kg.

What is the gross vehicle weight of the Burg BPA 16?

20,000 kg.

Up to what speed is the Burg BPA 16 approved?

Approved up to 100 km/h.

What are the dimensions of the Burg BPA 16?

9,350 mm × 2,500 mm.

When was the Burg BPA 16 built?

Production years: 1968-1972.

What to check before buying

  • Search the frame and welds at the axle mounts — that is where cracks start.
  • Check the brakes and the last inspection in the papers.
  • Work the gross weight against the towing vehicle before buying.
  • Compare the chassis number with the papers.
  • Look at the floor, cover or body from the inside — rust does not show from outside.

A general list for this type of machine — no substitute for an inspection or an appraiser.
