Start › Wheel loaders › Zettelmeyer › ZL302

Zettelmeyer ZL302

Series: Zettelmeyer Wheel Loader

Source: https://www.technikboerse.com/gebraucht/radlader-255/zettelm

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Zettelmeyer ZL302 is a model in the Zettelmeyer Wheel Loader series. The engine delivers 30 hp (21 kW), has 4 cylinders, with a displacement of 1,220.8 cm³. Torque is 76.1 Nm. Rated speed is 3,000 rpm. The unladen weight is 1,900 kg. The wheelbase measures 1,502.7 mm. Ground clearance is 231.6 mm. The tank holds 38.2 litres. The gearbox has 1 forward gears. There are also 1 reverse gears. Maximum torque is reached at 1,850 rpm. The pump delivers 21.2 l/min. The hydraulic tank holds 28 litres. The electrical system runs on 12 V. The engine fitted is the KHD F4 M 1008. Tyre size: 10,0/75-15,3. The Zettelmeyer Wheel Loader series covers 42 models. Rated output within it ranges from 30 to 306.2 hp; the ZL302 sits at the bottom of that range with 30 hp. Its immediate neighbours are the ZL8C above it with 35.4 hp. 50 Zettelmeyer models across 4 series are on record. The model is listed under Wheel loaders. 21 verified figures from 1 source are on file.

Technical data

Engine

Engine modelKHD F4 M 1008correct
Power30 hp (21 kW)correct
Rated speed3,000 rpmcorrect
Torque76.1correct
Speed at max. torque1,850 rpmcorrect
Cylinders4correct
Displacement1,220.8 cm³correct
Aspirationindirect injectioncorrect

Dimensions and weights

Wheelbase1,502.7correct
Ground clearance231.6correct
Unladen weight1,900 kgcorrect

Drivetrain and chassis

Gearbox typehydrostatic transmission full power shiftcorrect
Forward gears1correct
Reverse gears1correct
Tyre size10.0/75-15.3correct
System voltage12 Vcorrect

Working data

Pump flow21.2 l/mincorrect
Hydraulic oil capacity28 lcorrect
Fuel tank capacity38.2 lcorrect

Other data

Height2,310.4correct

Where this model stands

Power-to-weight ratio: 11.1 kW/t (21 kW / 1.9 t)

Stronger than 1% of the wheel loaders in the register — out of 1,253 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Zettelmeyer ZL302 have?

The Zettelmeyer ZL302 delivers 30 hp.

How much does the Zettelmeyer ZL302 weigh?

The unladen weight is 1,900 kg.

What engine does the Zettelmeyer ZL302 have?

4 cylinders, 1,221 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 21 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
