Zettelmeyer ZL1002i

Series: Zettelmeyer Wheel Loader

Source: https://www.mascus.de/baumaschinen/radlader/zettelmeyer-zl10

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The ZL1002i from Zettelmeyer is part of the Zettelmeyer Wheel Loader series. The engine delivers 93.3 hp (65.6 kW), has 4 cylinders, with a displacement of 4,760.4 cm³. Torque is 392.1 Nm. Rated speed is 2,100 rpm. The unladen weight is 7,600 kg. The wheelbase measures 2,401.8 mm. Ground clearance is 591.3 mm. The tank holds 100.3 litres. The gearbox has 2 forward gears. There are also 2 reverse gears. Maximum torque is reached at 1,400 rpm. The pump delivers 106.4 l/min. The hydraulic tank holds 110.2 litres. The electrical system runs on 24 V. The engine fitted is the KHD BF 4M 1013 E. Tyre size: 15,5-25. The Zettelmeyer Wheel Loader series covers 42 models. Rated output within it ranges from 30 to 306.2 hp; the ZL1002i sits in the lower part of that range with 93.3 hp. Its immediate neighbours are the ZL1001 below it with 85.2 hp and the ZL42C above it with 119.7 hp. 50 Zettelmeyer models across 4 series are on record. The model is listed under Wheel loaders. 21 verified figures from 1 source are on file.

Technical data

Engine

Engine modelKHD BF 4M 1013 Ecorrect
Power93.3 hp (65.6 kW)correct
Rated speed2,100 rpmcorrect
Torque392.1correct
Speed at max. torque1,400 rpmcorrect
Cylinders4correct
Displacement4,760.4 cm³correct
Aspirationturbo + water cooledcorrect

Dimensions and weights

Wheelbase2,401.8correct
Ground clearance591.3correct
Unladen weight7,600 kgcorrect

Drivetrain and chassis

Gearbox typehydrostatic transmission full power shiftcorrect
Forward gears2correct
Reverse gears2correct
Tyre size15.5-25correct
System voltage24 Vcorrect

Working data

Pump flow106.4 l/mincorrect
Hydraulic oil capacity110.2 lcorrect
Fuel tank capacity100.3 lcorrect

Other data

Height2,862.1correct

Where this model stands

Power-to-weight ratio: 8.6 kW/t (66 kW / 7.6 t)

Stronger than 33% of the wheel loaders in the register — out of 1,253 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Zettelmeyer ZL1002i have?

The Zettelmeyer ZL1002i delivers 93.3 hp.

How much does the Zettelmeyer ZL1002i weigh?

The unladen weight is 7,600 kg.

What engine does the Zettelmeyer ZL1002i have?

4 cylinders, 4,760 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
