Yanmar TF90V

Series: TF-V Series

Source: https://www.lectura-specs.com/en/model/components/engines-ya

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Yanmar TF90V belongs to the TF-V Series series. The engine delivers 9.5 hp (7 kW), has 1 cylinder. The engine is water-cooled. The fuel is diesel. The TF-V Series series covers 3 models. Rated output within it ranges from 7.5 to 12 hp; the TF90V sits in the middle of that range with 9.5 hp. Its immediate neighbours are the TF70V below it with 7.5 hp and the TF120V above it with 12 hp. 1231 Yanmar models across 70 series are on record.

Yanmar TF-V Series – horizontal single-cylinder diesel engines of the register: TF70V, TF90V and TF120V from Yanmar's industrial engine production

The Yanmar TF-V Series brings together on this collective page three horizontal single-cylinder diesel engines: TF70V, TF90V and TF120V. Like the rest of the TF range, these are horizontal single-cylinders with a low centre of gravity, easily mounted to pumps, generators and agricultural equipment; with power steps up to the TF120V, the V version covers the upper end of the TF range.

Read on 3 more paragraphs

The register lists here 3 versions: TF70V, TF90V and TF120V. Output ranges from 5.5 to 8.8 kW (7.5 to 12 hp) at displacements of 382 to 638 cm³ and rated speeds between 2,400 and 2,600 rpm; all three are water-cooled naturally aspirated single-cylinder engines running on diesel, dry weight lies between 78 and 116 kg.

Horizontal single-cylinder diesels such as the TF-V range drive irrigation pumps, small generator sets and agricultural drives worldwide; their simple construction, without elaborate cooling circuits or electronics, allows servicing away from well-equipped workshops too.

When buying used, what counts on these horizontal single-cylinders is compression, the condition of the injector and injection pump, and play in the crank train; on the more powerful versions such as the TF120V, it is also worth checking the clutch or pulley for wear. Spare parts run through Yanmar's industrial engine distribution.

Sources: SpecCodex register, model data: Yanmar TF-V Series, Yanmar (manufacturer)

Technical data

Engine

Fuel	dieselcorrect
Power	9.5 hp (7 kW)correct
Cylinders	1correct
Cooling	water-cooledcorrect

Dimensions and weights

Dry weight	97 kgcorrect

Other data

Aspiration	naturally aspiratedcorrect
Bore × stroke	85x87correct
Dimensions	725x342x500correct
Displacement	493 lcorrect
Speed	2,600 rpmcorrect

Frequently asked questions

How much power does the Yanmar TF90V have?

The Yanmar TF90V delivers 9.5 hp.

What engine does the Yanmar TF90V have?

1 cylinders, Diesel.

What to check before buying

Match the data plate against the order: frame size, mounting and rating have to agree.
For used units, ask about winding condition and bearing play.
Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
