KhTZ XTZ-243 – specifications
Series: XTZ-240
Build year not documented · Data origin: Reference work (Wikipedia/Wikibooks) · sources
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The XTZ-243 is an articulated steering tractor from the Kharkiv Tractor Plant lineup. It belongs to the XTZ-240 series and is powered by a water-cooled diesel engine. The vehicle is designed for agricultural use and utilizes an articulated steering system that enables high maneuverability on uneven terrain. The design follows the typical characteristics of heavy-duty tractors from this manufacturer line, with the specific model designation clarifying its classification within the existing series.
The six-cylinder engine with a displacement of 6,670 cm³ produces an output of 250 hp at a rated speed of 2,100 rpm. This engine configuration ensures that the tractor operates stably even under high loads and can drive large mounted implements. The ground clearance of 400 mm allows the vehicle to traverse obstacles and uneven surfaces without contacting the ground. The hydraulic lifting capacity is 5,000 kg, enabling the lifting and lowering of heavy work implements such as plows or seeders. These values define the practical operational capability of the vehicle in field conditions.
Within the XTZ-240 series, the XTZ-243 is positioned as a model with a six-cylinder drive. Compared to the XTZ-242 mentioned in the series description, which features an eight-cylinder engine with a displacement of 14,860 cm³ and 240 hp, the XTZ-243 offers higher output of 250 hp with smaller displacement. While the XTZ-242 provides different characteristics due to its eight cylinders, the XTZ-243 relies on the more compact design of the six-cylinder engine. Both models share the maximum lifting capacity of 5,000 kg, indicating a similar hydraulic design across the series.
XTZ-242 by the Kharkov Tractor Plant – water-cooled eight-cylinder engine with 14.9-litre displacement, 240 hp, 176 kW and a 5 t hydraulic lift capacity.
The XTZ-242 belongs to the XTZ-240 series from the Kharkov Tractor Plant and marks the top power class in the manufacturer's line-up. With an eight-cylinder engine, the plant adopts a drivetrain concept otherwise found in tractor building only in the very largest field tractors.
Read on 3 more paragraphs
The water-cooled eight-cylinder diesel engine, with a displacement of 14,860 cm³, delivers 240 hp, or 176 kW, at 2,100 rpm. The hydraulics lift up to 5,000 kg. With a wheelbase of 2,860 mm and a width of 2,460 mm, the tractor reaches a length of 6,596 mm and a height of 3,565 mm – dimensions that clearly place the XTZ-242 in the class of the heaviest field tractors.
Eight-cylinder tractors of this size are built for professional work on large arable fields, where heavy cultivators, wide ploughs and large seeding equipment demand both high pulling force and high hydraulic lift capacity at the same time. The large displacement of nearly 15 litres allows high torque at moderate engine speed, which benefits fuel consumption and engine wear in continuous operation.
When buying a used XTZ-242, the condition of the cooling system for the large-volume eight-cylinder engine is particularly important, as are the hydraulic pumps given the high 5,000 kg lift capacity. The engine, turbocharger and injection system should be checked by a specialist workshop before taking on such a large and complex machine second-hand. Spare parts, being less widespread outside the manufacturer's home region, are not equally available everywhere.
Sources: SpecCodex-Register: Kennwerte des Modells XTZ-242
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 250 hp (184 kW)correct |
| Rated speed | 2,100 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 6,670 cm³correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Ground clearance | 400 mmcorrect |
|---|
Working data
| Lifting capacity | 5,000 kgcorrect |
|---|
Origin and approval
| Construction | articulated framecorrect |
|---|
Frequently asked questions
How much power does the KhTZ XTZ-243 have?
The KhTZ XTZ-243 delivers 250 hp.
What engine does the KhTZ XTZ-243 have?
6 cylinders, 6,670 cm³ displacement, Diesel.
How much does the rear linkage of the KhTZ XTZ-243 lift?
The rear linkage lifts 5,000 kg.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
