Xtz HTZ-17321 – heavy eight-cylinder tractor: 10,850 cc displacement, 170 hp and 125 kW at 2,200 rpm, 2,480 mm wide and 6,640 mm long, water-cooled
XTZ stands for the Kharkiv Tractor Plant in Ukraine, which has built heavy wheeled agricultural tractors for decades. The HTZ-17321 belongs to the more powerful versions of this production line.
Read on 3 more paragraphs
The water-cooled eight-cylinder diesel engine has a displacement of 10,850 cc and produces 170 hp, or 125 kW, at 2,200 rpm. At 6,640 mm long, 2,480 mm wide, 3,370 mm high, with a 2,860 mm wheelbase and 450 mm ground clearance, the HTZ-17321 is a large, heavy tractor for field work.
Eight cylinders and over 10 litres of displacement for 170 hp point to a long-stroke tractor engine built for high drawbar pull at comparatively low revs. The generous 450 mm ground clearance allows work in tall-growing crops or on uneven ground without the underside of the machine grounding out.
When buying a used tractor this large and heavy, the condition of the eight-cylinder injection pump, the tightness of all radiator hoses and the wear on the steering knuckles of the wide front axle deserve particular attention. Given the high overall weight, it is also worth assessing tyre condition and the braking system, as both are worked harder than average at this mass, along with the PTO bearings where implements are used intensively. The value of such a machine hinges heavily on how complete its original service records are.
Sources: SpecCodex-Register: Kennwerte des Modells Xtz HTZ-17321
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 170 hp (125 kW)correct |
| Rated speed | 2,200 rpmcorrect |
| Cylinders | 8correct |
| Displacement | 10,850 cm³correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 6,640 mmcorrect |
|---|---|
| Width | 2,480 mmcorrect |
| Height | 3,370 mmcorrect |
| Wheelbase | 2,860 mmcorrect |
| Ground clearance | 450 mmcorrect |
Frequently asked questions
How much power does the KhTZ HTZ-17321 have?
The KhTZ HTZ-17321 delivers 170 hp.
What engine does the KhTZ HTZ-17321 have?
8 cylinders, 10,850 cm³ displacement, Diesel.
What are the dimensions of the KhTZ HTZ-17321?
6,640 mm × 2,480 mm × 3,370 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
