Woodford Trailers RL5-042
Built: 2013-2026 · Series: Other models
More machines from model year 2013
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Woodford Trailers – further models: the collection page for flatbed and box trailers of the FBT, LWT, RL and WBT series plus the Race Shuttle car transporter, 320 to 1,500 kg unladen weight, up to 3.5 t gross weight
This collection page gathers the Woodford Trailers models the register could not assign to a named series. The range spans the light flatbed trailers of the FBT series, the box trailers of the LWT series, the multi-step numbered RL, RL2, RL3, RL5, RL6 and RL7 types, and the WBT models; listed separately is the Race Shuttle, a car transporter trailer. The digits following the letter codes distinguish individual variants within a series.
Read on 3 more paragraphs
The register lists 37 versions with an unladen weight from 320 to 1,500 kg and a gross weight from 1,300 to 3,500 kg. Lengths range from 3.64 to 8.14 m, widths from 2.08 to 2.55 m.
These figures place the page firmly in the classic segment of trailers up to 3.5 t, from compact utility trailers to long transporters for race and sports cars. Such trailers serve private owners, trade businesses and motorsport teams alike.
When buying used, check the overrun brake coupling and brake linings, corrosion on the frame and loading-bed edges, and tyre condition and tread depth. On box versions, roof and door sealing also matter; on open platforms, the state of the floor covering does. Wiring and lights should be tested before the first journey; spare parts for axles and couplings are available from trailer specialists. Wheel bearings and hub seals should also be inspected on the heavier RL-series models.
Sources: SpecCodex register, model data: Woodford Trailers (weitere Modelle)
Technical data
Dimensions and weights
| Length | 7,000 mmcorrect |
|---|---|
| Width | 2,530 mmcorrect |
| Wheelbase | 4,910 mmcorrect |
| Unladen weight | 1,270 kgcorrect |
| Gross vehicle weight | 3,500 kgcorrect |
Drivetrain and chassis
| Wheels | 4correct |
|---|---|
| Top speed | 140 km/hcorrect |
Frequently asked questions
How much does the Woodford Trailers RL5-042 weigh?
The unladen weight is 1,270 kg.
What is the gross vehicle weight of the Woodford Trailers RL5-042?
3,500 kg.
Up to what speed is the Woodford Trailers RL5-042 approved?
Approved up to 140 km/h.
What are the dimensions of the Woodford Trailers RL5-042?
7,000 mm × 2,530 mm.
When was the Woodford Trailers RL5-042 built?
Production years: 2013-2026.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 10 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
