Valmet 305 (305/4)

Built: 1985–1989 · Series: 05 er-Baureihe

More machines from model year 1985

The photo shows the 405 (405/4) from the same series. Source: https://www.tractordata.com/farm-tractors/001/9/6/1961-valme

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Valmet 305 (305/4) belongs to the 05er series. Production: 1985–1989. The engine delivers 53 hp (39 kW), has 3 cylinders, with a displacement of 2,686 cm³. Torque is 179 Nm. Rated speed is 2,350 rpm. The machine is 3,710 mm long, 1,745 mm wide and 2,570 mm high. The unladen weight is 2,710 kg. The wheelbase measures 2,112 mm. Ground clearance is 460 mm. Top speed is 30 km/h. Transmission: 8 V/4 R and 12 V/8 R. The engine is water-cooled. Tyres: front 7.50-16 ASF (A: 11.2-24 AS), rear 13.6 R 36 AS. The fuel is diesel. The bore measures 100 mm. The stroke is 114 mm. The compression ratio is 17:1. Maximum torque is reached at 1,445 rpm. Construction: unit construction (no separate frame). The 05 er-Baureihe series covers 3 models. Rated output within it ranges from 49 to 61 hp; the 305 (305/4) sits in the lower part of that range with 53 hp. Its immediate neighbours are the 205/205-4 below it with 49 hp and the 405 (405/4) above it with 61 hp. 414 Valmet models across 21 series are on record.

Valmet 05 range: collective page of Finnish tractors 205, 305 and 405 from Suolahti, three-cylinder 2,686 cm³ diesels, 36 to 45 kW

The 05 range from Valmet, with the models 205, 305 and 405, was built at the Finnish plant in Suolahti; the model numbers rank the three versions by power class, and the -4 suffix denotes the four-wheel-drive variant in each case. Unlike Valmet's larger ranges, the 05 range was deliberately kept technically simple, favouring robustness over added complexity. That simplicity became a selling point in the field. Valmet was the name of the Finnish farm-machinery works in Suolahti until the tractor division was renamed Valtra in the 1990s.

Read on 3 more paragraphs

The register lists 3 versions with 36 to 44.9 kW from three-cylinder diesel engines of 2,686 cm³, an unladen weight of 2,710 kg, a length of 3,710 mm, widths of 1,745 to 1,950 mm and heights of 2,560 to 2,615 mm; torque ranges from 175 to 202 Nm at a rated speed of 2,350 rpm.

Tractors in this power class were popular all-round machines on Finnish and Scandinavian farms, suited to the shorter growing season of the north, and competed with comparable ranges from Volvo BM and Nordic import brands.

When buying used, condition of the three-cylinder diesel including cooling and injection, the gearbox and clutch, and on four-wheel-drive versions the front axle bearings all matter; spare parts are available through today's Valtra network and independent farm-machinery dealers in Scandinavia.

Sources: SpecCodex register, model data: Valmet 05er

Technical data

Engine

Fuel	dieselcorrect
Power	53 hp (39 kW)correct
Rated speed	2,350 rpmcorrect
Torque	179 Nmcorrect
Speed at max. torque	1,445 rpmcorrect
Cylinders	3correct
Displacement	2,686 cm³correct
Bore	100 mmcorrect
Stroke	114 mmcorrect
Compression ratio	17correct
Cooling	water-cooledcorrect

Dimensions and weights

Length	3,710 mmcorrect
Width	1,745 mmcorrect
Height	2,570 mmcorrect
Wheelbase	2,112 mmcorrect
Ground clearance	460 mmcorrect
Unladen weight	2,710 kgcorrect

Drivetrain and chassis

Drive	rear- or four-wheel drivecorrect
Gearbox	8 V/4 R and 12 V/8 Rcorrect
Front tyres	7.50-16 ASF (A: 11.2-24 AS)correct
Rear tyres	13.6 R 36 AScorrect
Top speed	30 km/hcorrect

Origin and approval

Construction	unit construction (no separate frame)correct

Where this model stands

Power-to-weight ratio: 14.4 kW/t (39 kW / 2.7 t)

Power class: Universal (40–100 hp)

Stronger than 37% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Valmet 305 (305/4) have?

The Valmet 305 (305/4) delivers 53 hp.

How much does the Valmet 305 (305/4) weigh?

The unladen weight is 2,710 kg.

What engine does the Valmet 305 (305/4) have?

3 cylinders, 2,686 cm³ displacement, Diesel.

How fast does the Valmet 305 (305/4) go?

Top speed is 30 km/h.

What are the dimensions of the Valmet 305 (305/4)?

3,710 mm × 1,745 mm × 2,570 mm.

When was the Valmet 305 (305/4) built?

Production years: 1985–1989.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
