Ursus/zm C-360

Built: 1976–1994 · Series: Other models

More machines from model year 1976

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Pozostałe modele series from Ursus/zm includes the C-360. Production: 1976–1994. The engine delivers 52 hp (38.2 kW), has 4 cylinders, with a displacement of 3,119 cm³. Torque is 190 Nm. Rated speed is 2,200 rpm. The machine is 3,571 mm long, 1,800 mm wide and 2,050 mm high. The unladen weight is 2,170 kg. The wheelbase measures 2,125 mm. Ground clearance is 395 mm. Top speed is 25 km/h. Transmission: 10 V/2 R. The engine is water-cooled. Tyres: front 6.00-16 ASF, rear 14.9-28 AS. The fuel is diesel. The bore measures 95 mm. The stroke is 110 mm. The compression ratio is 17:1. Construction: unit construction (no separate frame). Rated output across the Ursus/zm range ranges from 45 to 52 hp; the C-360 sits at the top of that range with 52 hp. Its immediate neighbours are the C-355 P below it with 50 hp. Rated output across the Ursus/zm range ranges from 33.1 to 38.2 kW; here the C-360 sits at the top of that range with 38.2 kW. 5 Ursus/zm models are on record.

Ursus ZM – other models: the collective page of Zakłady Mechaniczne Ursus, C-350 to C-362 with the most widely built C-360, 33 to 38 kW

This page gathers the tractors of Zakłady Mechaniczne Ursus (Ursus ZM) the register could not assign to a named range – the C-350 range, whose best-known model, the C-360, is among the most widely built tractors in Poland. The types C-350, C-355 P, C-360, C-360 3P and C-362 follow Ursus's typical C numbering; P and 3P mark equipment variants.

Read on 3 more paragraphs

The register lists here 5 versions with 33.1 to 38.2 kW from three- to four-cylinders of 2,502 to 3,119 cc, unladen weights from 2,056 to 2,624 kg, lengths from 3,250 to 3,630 mm, widths from 1,670 to 1,800 mm and heights from 1,620 to 2,690 mm, torque from 165 to 193 Nm at rated speeds of 2,000 to 2,250 rpm.

The Ursus C-360 and its sister models were, for decades, the standard tractors of Polish agriculture and are still in use in large numbers on Polish farms today; their simple, sturdy design also made them suitable for export to other Eastern Bloc countries.

On the C-350 range, what counts is the condition and compression of the three- or four-cylinder diesel, the condition of clutch and gearbox, the tightness of the hydraulics, and rust on bodywork and cab; since these models were built in very large numbers, parts are still widely available in Poland today, as well as the working order of the lighting, instruments, cab heating and the tightness of the windows.

Sources: SpecCodex register, model data: Ursus ZM (weitere Modelle), Ursus (manufacturer)

Technical data

Engine

Fuel	dieselcorrect
Power	52 hp (38.2 kW)correct
Rated speed	2,200 rpmcorrect
Torque	190 Nmcorrect
Cylinders	4correct
Displacement	3,119 cm³correct
Bore	95 mmcorrect
Stroke	110 mmcorrect
Compression ratio	17correct
Cooling	water-cooledcorrect

Dimensions and weights

Length	3,571 mmcorrect
Width	1,800 mmcorrect
Height	2,050 mmcorrect
Wheelbase	2,125 mmcorrect
Ground clearance	395 mmcorrect
Unladen weight	2,170 kgcorrect

Drivetrain and chassis

Drive	rear-wheel drivecorrect
Gearbox	10 V/2 Rcorrect
Front tyres	6.00-16 ASFcorrect
Rear tyres	14.9-28 AScorrect
Top speed	25 km/hcorrect

Origin and approval

Construction	unit construction (no separate frame)correct

Where this model stands

Power-to-weight ratio: 17.6 kW/t (38 kW / 2.2 t)

Power class: Universal (40–100 hp)

Stronger than 36% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Ursus/zm C-360 have?

The Ursus/zm C-360 delivers 52 hp.

How much does the Ursus/zm C-360 weigh?

The unladen weight is 2,170 kg.

What engine does the Ursus/zm C-360 have?

4 cylinders, 3,119 cm³ displacement, Diesel.

How fast does the Ursus/zm C-360 go?

Top speed is 25 km/h.

What are the dimensions of the Ursus/zm C-360?

3,571 mm × 1,800 mm × 2,050 mm.

When was the Ursus/zm C-360 built?

Production years: 1976–1994.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
