Tong Yang Moolsan T603 NC PS 4WD
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
As a tractor, the Tong Yang Moolsan T603 NC PS belongs to the Tong Yang Moolsan 4WD Tractor series. Under the bonnet works a four-cylinder engine displacing 2.2 litres, producing 59 hp (43.3 kW). Rated power is reached at 2,600 rpm.
At 36 km/h, that is as fast as it goes. Empty, it weighs 2,360 kg.
Within the range, rated power spans from 23.3 to 101 hp; with 58.8 hp, the T603 NC PS sits in the upper third. Directly alongside are the T503 NC with 51.4 hp below and the T903 with 90.3 hp above.
Tong Yang Moolsan – other models: the collective page of South Korean compact tractors outside the named ranges, from the T233HST and T353 to the T603 and T903, 17 to 74 kW, Caterpillar and Mitsubishi engines
This page gathers the Tong Yang Moolsan tractors the register could not assign to a named range – compact and utility tractors of the T range, from the T1003 through the T233HST, T273HST, T353, T433, T503 to the T603 and T903, some with cab (CAB) and some without (NC). Tong Yang Moolsan was a South Korean tractor maker whose programme was later continued under the name TYM; the model designation T with a number gives the range, HST stands for the hydrostatic transmission. The machines are powered by Caterpillar C2.2 diesel engines and by the Mitsubishi S3L2 and S4L2 engines.
Read on 3 more paragraphs
The register lists here 14 versions with 17.2 to 74 kW from three- and four-cylinders of 1,125.8 to 4,398.3 cm³, unladen weights from 920 to 3,685 kg, lift capacities from 500 to 2,490 kg, lengths from 2,740 to 4,110 mm, PTO outputs from 17 to 88 hp and rated speeds from 2,200 to 2,800 rpm.
Tong Yang Moolsan was among the South Korean makers that from the 1980s built compact tractors for export to North America and Europe, where alongside Kubota and Iseki they were positioned as a lower-cost alternative for hobby farms, municipalities and smaller operations.
On used examples of these compact tractors, operating hours, the condition of the hydrostatic or gear transmission, the tightness of the front hydraulics and PTO, and rust on cab and bonnet count; parts run partly through TYM importers, partly through independent farm-machinery dealers.
Sources: Kennwerte der Modelle Tong Yang Moolsan (weitere Modelle)
Technical data
Engine
| Engine model | C2.2Tcorrect |
|---|---|
| Power | 58.8 hp (43.3 kW)correct |
| Rated speed | 2,600 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 2,215.5 cm³correct |
| Aspiration | turbochargedcorrect |
| Coolant capacity | 9.1 lcorrect |
| Engine oil capacity | 6.8 lcorrect |
Dimensions and weights
| Length | 3,720 mmcorrect |
|---|---|
| Unladen weight | 2,360 kgcorrect |
Drivetrain and chassis
| Gearbox type | sync/shuttlecorrect |
|---|---|
| Forward gears | 24correct |
| Reverse gears | 24correct |
| Tyre size | front 12-16.5R4 rear 16.9-24R4correct |
| Top speed | 35.6 km/hcorrect |
| Turning radius | 3,840 mmcorrect |
Working data
| Lifting capacity | 1,147 kgcorrect |
|---|---|
| Pump flow | 57.5 l/mincorrect |
| Hydraulic oil capacity | 42 lcorrect |
| Fuel tank capacity | 70 lcorrect |
Other data
| Cab height | 2,590.8correct |
|---|---|
| PTO output | 47 hpcorrect |
| System voltage | 12 Vcorrect |
More machines with this engine (C2.2T, 5)
Where this model stands
Power-to-weight ratio: 18.3 kW/t (43 kW / 2.4 t)
Power class: Universal (40–100 hp)
Stronger than 41% of the tractors in the register — out of 15,659 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Tong Yang Moolsan T603 NC PS have?
The Tong Yang Moolsan T603 NC PS delivers 58.8 hp.
How much does the Tong Yang Moolsan T603 NC PS weigh?
The unladen weight is 2,360 kg.
What engine does the Tong Yang Moolsan T603 NC PS have?
4 cylinders, 2,216 cm³ displacement.
How fast does the Tong Yang Moolsan T603 NC PS go?
Top speed is 35.6 km/h.
What is the PTO output of the Tong Yang Moolsan T603 NC PS?
PTO output is 47 hp.
How much does the rear linkage of the Tong Yang Moolsan T603 NC PS lift?
The rear linkage lifts 1,147 kg.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
