Tong Yang Moolsan T1003 4WD
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
As a tractor, the Tong Yang Moolsan T1003 belongs to the Tong Yang Moolsan 4WD Tractor series. Under the bonnet works a four-cylinder engine displacing 4.4 litres, producing 101 hp (74 kW). Rated power is reached at 2,200 rpm.
At 40 km/h, that is as fast as it goes. Empty, it weighs 3,685 kg.
Within the range, rated power spans from 23.3 to 101 hp; with 101 hp, the T1003 sits at the top. Below it ranks the T903 with 90.3 hp.
Technical data
Engine
| Engine model | 3054C-DITcorrect |
|---|---|
| Power | 100.6 hp (74 kW)correct |
| Rated speed | 2,200 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 4,398.3 cm³correct |
| Coolant capacity | 11.4 lcorrect |
| Engine oil capacity | 6.8 lcorrect |
Dimensions and weights
| Unladen weight | 3,685 kgcorrect |
|---|
Drivetrain and chassis
| Gearbox type | sync/power shuttlecorrect |
|---|---|
| Forward gears | 32correct |
| Reverse gears | 32correct |
| Tyre size | front 13.6-24-8PR rear 16.9-34-8PRcorrect |
| Top speed | 40.1 km/hcorrect |
| System voltage | 12 Vcorrect |
Working data
| Pump flow | 83.7 l/mincorrect |
|---|---|
| Hydraulic oil capacity | 75.3 lcorrect |
| Fuel tank capacity | 125.3 lcorrect |
Other data
| Height | 2,718.8correct |
|---|
Where this model stands
Power-to-weight ratio: 20.1 kW/t (74 kW / 3.7 t)
Power class: Large (100–180 hp)
Stronger than 67% of the tractors in the register — out of 15,240 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Tong Yang Moolsan T1003 have?
The Tong Yang Moolsan T1003 delivers 101 hp.
How much does the Tong Yang Moolsan T1003 weigh?
The unladen weight is 3,685 kg.
What engine does the Tong Yang Moolsan T1003 have?
4 cylinders, 4,398 cm³ displacement.
How fast does the Tong Yang Moolsan T1003 go?
Top speed is 40.1 km/h.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 19 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
