Terex RT500-1

Series: Terex Rough Terrain Crane

Source: https://www.terex.com/rough-terrain-cranes/en/products/rough

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Terex Rough Terrain Crane series from Terex includes the RT500-1. The engine delivers 192.6 hp (138 kW), with a displacement of 5,899.3 cm³. Torque is 743 Nm. Rated speed is 2,400 rpm. The unladen weight is 34,850.4 kg. Ground clearance is 566.9 mm. The tank holds 302.8 litres. The gearbox has 6 forward gears. There are also 6 reverse gears. Maximum torque is reached at 1,400 rpm. The hydraulic tank holds 424 litres. The electrical system runs on 24 V. The engine fitted is the QSB185. Tyre size: 26,5x25. 26 P,R,. The Terex Rough Terrain Crane series covers 35 models. Rated output within it ranges from 131.8 to 304.2 hp; the RT500-1 sits in the lower part of that range with 192.6 hp. Its immediate neighbours are the RT555-1 below it with 187.6 hp and the A600 above it with 202.7 hp. 377 Terex models across 29 series are on record. The model is listed under Cranes & access platforms. 17 verified figures from 1 source are on file.

Technical data

Engine

Engine modelQSB185correct
Power192.6 hp (138 kW)correct
Rated speed2,400 rpmcorrect
Torque743correct
Speed at max. torque1,400 rpmcorrect
Displacement5,899.3 cm³correct
AspirationTurbocharged, charge air cooledcorrect

Dimensions and weights

Ground clearance566.9correct
Unladen weight34,850.4 kgcorrect

Drivetrain and chassis

Gearbox typePower-Shift Transmissioncorrect
Forward gears6correct
Reverse gears6correct
Tyre size26.5x25, 26 P.R.correct
System voltage24 Vcorrect

Working data

Hydraulic oil capacity424 lcorrect
Fuel tank capacity302.8 lcorrect

Where this model stands

Power-to-weight ratio: 4 kW/t (138 kW / 34.9 t)

Stronger than 26% of the mobile & rough terrain cranes in the register — out of 591 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Terex RT500-1 have?

The Terex RT500-1 delivers 193 hp.

How much does the Terex RT500-1 weigh?

The unladen weight is 34,850 kg.

What engine does the Terex RT500-1 have?

5,899 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 17 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
