Terex AT-15

Series: Terex Rough Terrain Crane

Source: https://commons.wikimedia.org/w/index.php?curid=73588599

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Terex AT-15 belongs to the Terex Rough Terrain Crane series. The engine delivers 170 kW. Torque is 710 Nm. Rated speed is 2,200 rpm. Ground clearance is 256 mm. The tank holds 330.1 litres. The gearbox has 5 forward gears. Maximum torque is reached at 1,000 rpm. The hydraulic tank holds 120.4 litres. The engine fitted is the OM906LA. Tyre size: 11,00 x 20 Bias Ply Duals. The Terex Rough Terrain Crane series covers 35 models. Rated output within it ranges from 96.9 to 223.7 kW; the AT-15 sits in the middle of that range with 170 kW. Its immediate neighbours are the RT670 below it with 165 kW and the RT1000 above it with 193.9 kW. 377 Terex models across 29 series are on record. The model is listed under Cranes & access platforms. 12 verified figures from 1 source are on file.

Technical data

Engine

Engine modelOM906LAcorrect
Power170 kWcorrect
Rated speed2,200 rpmcorrect
Torque710correct
Speed at max. torque1,000 rpmcorrect
AspirationTurbocharged + intercooledcorrect

Dimensions and weights

Ground clearance256correct

Drivetrain and chassis

Gearbox typeAllison 2000correct
Forward gears5correct
Tyre size11.00 x 20 Bias Ply Dualscorrect

Working data

Hydraulic oil capacity120.4 lcorrect
Fuel tank capacity330.1 lcorrect

Frequently asked questions

How much power does the Terex AT-15 have?

The Terex AT-15 delivers 170 kW.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 12 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
