Start › Mobile & rough terrain cranes › Terex › CD200

Terex CD200

Series: Terex Rough Terrain Crane

Source: https://www.kleinanzeigen.de/s-anzeige/arbeitsbuehne-20m-hub

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The CD200 from Terex is part of the Terex Rough Terrain Crane series. The engine delivers 131.8 hp (96.9 kW), with a displacement of 5,883 cm³. Torque is 520.6 Nm. Rated speed is 2,500 rpm. The unladen weight is 19,293.1 kg. Ground clearance is 460.2 mm. The tank holds 189.3 litres. The gearbox has 6 forward gears. There are also 6 reverse gears. Maximum torque is reached at 1,200 rpm. The hydraulic tank holds 344.1 litres. The electrical system runs on 24 V. The engine fitted is the 6BTA5,9. Tyre size: 14,00 x 24. 20 P,R,. The Terex Rough Terrain Crane series covers 35 models. Rated output within it ranges from 131.8 to 304.2 hp; the CD200 sits at the bottom of that range with 131.8 hp. Its immediate neighbours are the RT35 above it with 141.4 hp. 377 Terex models across 29 series are on record. The model is listed under Cranes & access platforms. 17 verified figures from 1 source are on file.

Technical data

Engine

Engine model6BTA5.9correct
Power131.8 hp (96.9 kW)correct
Rated speed2,500 rpmcorrect
Torque520.6correct
Speed at max. torque1,200 rpmcorrect
Displacement5,883 cm³correct
Aspirationturbochargedcorrect

Dimensions and weights

Ground clearance460.2correct
Unladen weight19,293.1 kgcorrect

Drivetrain and chassis

Gearbox typePower-Shift Transmissioncorrect
Forward gears6correct
Reverse gears6correct
Tyre size14.00 x 24, 20 P.R.correct
System voltage24 Vcorrect

Working data

Hydraulic oil capacity344.1 lcorrect
Fuel tank capacity189.3 lcorrect

Where this model stands

Power-to-weight ratio: 5 kW/t (97 kW / 19.3 t)

Stronger than 8% of the mobile & rough terrain cranes in the register — out of 591 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Terex CD200 have?

The Terex CD200 delivers 132 hp.

How much does the Terex CD200 weigh?

The unladen weight is 19,293 kg.

What engine does the Terex CD200 have?

5,883 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 17 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
