Terex RT300-1

Series: Terex Rough Terrain Crane

Source: https://www.bigge.com/crane-information/terex-rt-340/

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Terex Rough Terrain Crane series from Terex includes the RT300-1. The engine delivers 162.2 hp (115.6 kW), with a displacement of 5,899.3 cm³. Torque is 596.6 Nm. Rated speed is 2,500 rpm. The unladen weight is 28,694.3 kg. Ground clearance is 475.5 mm. The tank holds 189.3 litres. The gearbox has 6 forward gears. There are also 6 reverse gears. Maximum torque is reached at 1,500 rpm. The hydraulic tank holds 431.5 litres. The electrical system runs on 24 V. The engine fitted is the QSB5,9. Tyre size: 23,5R25. The Terex Rough Terrain Crane series covers 35 models. Rated output within it ranges from 131.8 to 304.2 hp; the RT300-1 sits in the lower part of that range with 162.2 hp. Its immediate neighbours are the RC40 below it with 161.8 hp and the RT45 above it with 175.4 hp. 377 Terex models across 29 series are on record. The model is listed under Cranes & access platforms. 17 verified figures from 1 source are on file.

Technical data

Engine

Engine modelQSB5.9correct
Power162.2 hp (115.6 kW)correct
Rated speed2,500 rpmcorrect
Torque596.6correct
Speed at max. torque1,500 rpmcorrect
Displacement5,899.3 cm³correct
Aspirationturbochargedcorrect

Dimensions and weights

Ground clearance475.5correct
Unladen weight28,694.3 kgcorrect

Drivetrain and chassis

Gearbox typepowershift transmission Transmissioncorrect
Forward gears6correct
Reverse gears6correct
Tyre size23.5R25correct
System voltage24 Vcorrect

Working data

Hydraulic oil capacity431.5 lcorrect
Fuel tank capacity189.3 lcorrect

Where this model stands

Power-to-weight ratio: 4 kW/t (116 kW / 28.7 t)

Stronger than 16% of the mobile & rough terrain cranes in the register — out of 591 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Terex RT300-1 have?

The Terex RT300-1 delivers 162 hp.

How much does the Terex RT300-1 weigh?

The unladen weight is 28,694 kg.

What engine does the Terex RT300-1 have?

5,899 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
